Ø LCD Digital Display
The main interface (Level 1) is the default interface, the inverter will
automatically jump to this interface when the system started up
successfully or not operated for a period of time.
The interface shows the information of “Power”, “Pgrid”, “Today”, “Total”. Press
”Up“ and “Down” to review the information.
Ø Menu interface
The menu interface (Level 2) is a transfer interface for the user to get into
other interface to finish the setting or get the information.
-User can get into this interface by long pressing “Down” button when LCD
displays the main interface.
-User can select by moving the cursor with function button, and long press
“Down” to confirm.
Ÿ Status
The status function contains two aspects, the grid and the solar.
Press ”Up“ and “Down” to select and long press “down” to confirm the
selection, long press “Up” to return to Menu.
a) Grid
This status shows the current grid condition such as voltage, current,
output power and grid power. Pout measures the output of the inverter,
Pgrid measures power export to or import from grid. Positive value means
the power feeds into grid, negative value means the power used from the
grid.
Press ”Up“ and “Down” button to review the parameter, long press “up” to
return to Status .
Power 0W
Normal
Status
Language
Grid
Solar
Status
﹦ ﹦ ﹦ ﹦
Menu
﹦ ﹦ ﹦ ﹦
﹦ ﹦ ﹦ ﹦ ﹦ ﹦ ﹦ ﹦
> Pu_3Tau
10.0S
>VacOvp1stTime
0.10S
Up
Down
>VacOvp2ndTime
0.10S
Up
Down
Up
Down
>FacUfp1stTime
>FacUfp2ndTime
Up
Down
0.10S
0.10S
>VacUvp1stTime
>VacUvp2ndTime
Up
Down
>FacOfp1stTime
Up
Down
>FacOfp2ndTime
Up
Down
Up
Down
3.00S
0.30S
0.10S
0.10S
