Solcon TPR-6 User Manual

18 • Mode Pages Display
________________________________________________________________________________________________
6.5 Statistical Data
The following demonstrates the readings with the following settings in TEMPERATURE SETTINGS:
T1 SENSOR TYPE is set to RTD
T2 SENSOR TYPE is set to PTC THERMISTOR
T3 SENSOR TYPE is set to PTC THERMISTOR
Press SELECT
When sensor type is set as Thermistor
display will show:
Press SELECT
Press SELECT
Press SELECT
Press SELECT
Press SELECT
Press SELECT
Press SELECT
Press SELECT
STATISTICAL DATA
- **** -
T1 – MAX. VALUE
255 deg C
LAST TRIP
T1 LEVEL 1
LAST ALARM
NO DATA
TOTAL # OF TRIPS
0
T1 AT TRIP TIME
255 deg. C
R2 AT TRIP TIME
0 KOHM
R2 – MAX. VALUE
25.5 KOHM
R3 – MAX. VALUE
25.5 KOHM
R3 AT TRIP TIME
0 KOHM
255 deg C
Note: When in the STATISTICAL DATA displays,
pressing RESET for more than 1 second, will zero the
display screen.
More than One Alarm or Trip.
The TPR-6 is designed to accept and store the first
alarm it detects. If this alarm has not been reset and
an additional alarm occurs, the TPR-6 will not display
the second alarm on the LCD nor assign it to the
STATISTICAL DATA.
In case a trip occurs after an alarm, the trip message
will override the alarm message.
This is to assist the user in establishing the cause of
the alarm.
Attention !
Resetting Statistical Data resets all previous statistical
data values ! ! !
The last two actions (store DEFAULT SETTINGS and
clearing STATISTICAL DATA in SERVICE MODE page)
should be done with care, since it is not possible to
retrieve the previous set point parameters or statistical
data.
