6.2 Parameter Setting – I/O Settings
Press SELECT
Configure Alarm Relay function
Press ▲ or▼ keys to set required operation mode
Range: ALARM, ALARM FAIL SAFE, TRIPPING/ALARM
ALARM - the relay changes position upon trip and returns to original position upon reset, after fault has been
removed.
ALARM FAIL SAFE - the relay changes position upon voltage connection and returns to original position
upon fault.
TRIPPING / ALARM - Relay can be assigned to specific faults that are enabled as alarm or trip.
Press SELECT
Configure Trip Relay function
Press ▲ or▼ keys to set required operation mode
Range: TRIP, TRIP FAIL SAFE, TRIPPING/ALARM
TRIP - the relay changes position upon trip and returns to original position upon reset, after fault has been
removed.
TRIP FAIL SAFE - the relay changes position upon voltage connection and return to original position upon
fault.
TRIPPING / ALARM - Relay can be assigned to specific faults that are enabled as alarm or trip.
Press SELECT
Configure input 1 function
Press ▲ or▼ keys to set required input function for INPUT 1.
Range: REMOTE RESET, EXTERNAL FAULT 1 N.O., EXTERNAL FAULT 1 N.C.
Press SELECT
Configure Trip Relay function
Press ▲ or▼ keys to set required input function for INPUT 2.
Range: REMOTE RESET, EXTERNAL FAULT 2 N.O., EXTERNAL FAULT 2 N.C.
Press SELECT
Configure Analogue Output
Press ▲ or▼ keys to configure the analog output.
Range: 0-20mA NORMAL, 4-20mA NORMAL, 0-20mA INVERTED and 4-20mA INVERTED
To Next Page
