4 • Introduction
________________________________________________________________________________________________
Statistical data
Max. value of each sensor
Last trip
Last alarm
Total number of trips
Temperature / Resistance of each sensor at time of trip
All above parameters can be individually configured through a keypad on the front panel or through
communication.
The Liquid Crystal Display (LCD), together with a Keypad and LEDs enables user friendly interface, accurate
digital parameters setting, actual parameters readings, and detailed trip and alarm message displays.
Changes can easily be prevented by the usage of the parameter lock feature.
RS485 serial link (with MODBUS communication protocols), operating at baud rate of 1200 to 19200 bits/sec.
enables monitoring of both the set points and actual parameters. Changes of the set points parameters
through the serial link makes it very easy to enter customer set points in place of the factory default
parameters. Parameter setting through the serial link may be easily disabled through manual keypad setting.
Up to 32 TPR-6 units can be connected on the same link to the host computer.
