6-2. Specifications
Dimensions, design and all specifications are subject to change without any prior
notice.
Product Name 15” TFT-LCD TV
LCD Panel Type Amorphos Silicon TFT-LCD
Size 15” (diagonal length)
Pixel Pitch 0.297 mm x 0.297 mm
Contrast Ratio 500 : 1 (Typ.)
Brightness 450 cd /
Actual Display Size 304.1mm (H) x 228.1mm (V)
Viewing Angle L/R : 130° U/D : 100°
Interface LVDS
TV Broadcasting System NTSC-M Type
Audio Output MAX 3W x 2 / Stereo
PC Monitor Horizontal Frequency 30 ~ 61 KHz
Vertical Frequency 60~ 75 Hz
Colors 16M colors
Max. Resolution XGA : 1024 (H) x 768 (V)
Power Adaptor Input AC 100V~240V, 50~60Hz
Adaptor Output DC 12 V
Power Consumption In-Operation < 40W
Power-Saving Mode/OFF < 5W
Energy Saving Mode VESA DPMS
55
PAL/SECAM
EN 54
15 TFT-LCD TV
6-1.Dimentions
Weight : approx. 4.5kg (before packing) / approx. 5.9kg (after packing)
35.6mm
17.5mm
356mm
323mm
323mm
To Next Page
