1. Introduction
Congratulations on your purchase of Solectek’s SkyWay Access Series Multipoint Radio System, a
feature rich, best-in-class wireless solution. This User’s Guide will describe the operation of your
SkyWay unit in detail.
A. System Features
• Field proven OFDM modulation allowing high capacity, near line-of-sight deployment and
strong immunity to multi-path.
• MIMO architecture for increased capacity – 300 Mbps Data Rate.
• Polling MAC architecture for high network capacity and supporting a large number of client
units.
• Modulation control of individual Client units in both TX and Rx.
• Power over Ethernet (PoE) for simplified cable routing.
• Integrated or built-in antenna/radio simplifies installation and eliminates lossy RF coax runs.
• Frame aggregation for enhanced data throughput.
• Line speed QoS packet inspection prioritizes latency sensitive, real-time data.
• Intuitive Web based user interface and Telnet CLI.
B. Applicable Models
• AS5800: Base Station, 26dBm output power,
• AS5810: Long-Range Client unit, aluminum enclosure, IP67, 23dBm, 23 dBi antenna
• AS5830: Short-Range Client unit, aluminum enclosure, 23dBm, 20 dBi antenna
AS5800 AS5810 AS5830
C. Kit Contents
AS5800 Base Station
• SkyWay-Access radio unit
• Power over Ethernet (PoE) injector / 48V DC Power Supply
• Mast mounting kit
• CAT5 weatherproofing feed-through
• Weather sealing tape
• Warranty/compliance and customer information Card.
