Solid State Logic Alpha-Link AX User Manual

14
Virtual Switches, Page One (Alpha-Link AX, MADI-AX and MADI-SX)
Settings in bold indicate defaults. Please also refer to the notes overleaf for details regarding each setting.
LED Option Setting LED State See Note
1 Number of MADI channels (not AX)
64 (32 at 2Fs)
1.
56 (28 at 2Fs)
2 MADI 2Fs data format (not AX)
High Speed
2.
Legacy (SMUX)
3 AES/EBU 2Fs data format (MADI-SX)
High Speed
2.
Legacy (SMUX)
4 Analogue/Digital connection mode
Analogue first (lowest)
3.
Digital first (lowest)
5 ADAT or AES/EBU channel status
Use
4.
Ignore
6
Sample rate when an Fs rate signal
is applied to the wordclock input
Fs
5.
2Fs
7 Wordclock output at 2Fs
Fs Clock
6.
2Fs Clock
8 Phase angle of Wordclock output
0°
7.
90°
