Solid State Logic Alpha-Link AX User Manual

15
Virtual Switches, Page One (Alpha-Link LIVE)
Settings in bold indicate defaults. Please also refer to the notes opposite for details of each setting.
LED Option Setting LED State See Note
1 Number of MADI channels
64 (32 at 2Fs)
1.
56 (28 at 2Fs)
2 MADI 2Fs data format
High Speed
2.
Legacy (SMUX)
3 AES/EBU 2Fs data format
High Speed
2.
Legacy (SMUX)
4 Analogue/Digital connection mode
Analogue first (lowest)
3.
Digital first (lowest)
5 AES/EBU channel status
Use
4.
Ignore
6
Sample rate when an Fs rate signal
is applied to the wordclock input
Fs
5.
2Fs
7 Wordclock output at 2Fs
Fs Clock
6.
2Fs Clock
8 Phase angle of Wordclock output
0°
7.
90°
