Virtual Switches, Page Two (Alpha-Link AX and MADI-AX)

Settings in bold indicate defaults. Please refer to the notes overleaf for details regarding each setting.

LED Option Setting LED States See Note

1

2

ADAT clock source

ADAT In 1 –8

1.ADAT In 9 – 16

ADAT In 17 – 24

3 Clock source for ‘External’ selection

Wordclock

2.

MADI (MADI-AX only)

4 Unused n/a n/a –

5 Unused n/a n/a –

6 Unused n/a n/a –

7 Unused n/a n/a –

8 Unused n/a n/a –
