Solid State Logic C100 HDS Software Update Manual

C100 HDS Software Update
Page 18
Playlists can be set to either play through the list of Cuts without pausing, or to pause between each Cut until it is manually
triggered. This is done using the Auto/Manual button beneath the Save As button: To cause the Playlist to play without
requiring manual triggering, set the button to Auto (button lit). To make the Playlist pause between Cuts, set the button
to Manual (button unlit). Playlists are prefixed with an ‘A’ in the main Playlist list to indicate when they are in Auto mode.
To remove a Cut from the Playlist, use the Master Scroller to highlight the Cut to be deleted, then touch the Delete
button.
Note that the Delete button only deletes Cuts from the Playlist, not from C-Play.
To re-order the Cuts in the Playlist, use the Scroller to highlight the Cut to be moved, touch the Move button, then scroll
to the new location and press the Scroller.
Auditioning Cuts and Playlists
It is possible to listen to Cuts which you intend to add to a Playlist, or which have already been included in the Playlist. This
is done by activating the Audition button towards the base of the Edit Playlist window, and then selecting the Cut you wish
to play using the Master Scroller. This function works whether the display is showing the Playlist’s Cuts, or the full Cuts
List as part of the Append or Insert procedures.
When auditioning Cuts already added to the Playlist, it is possible to include the transition from the previous Cut in the
Playlist, by activating the Pre Roll button. To adjust how much of the previous Cut you hear as part of the audition, touch
the blue value box to the right of the Pre Roll button, enter a time value (in seconds) in the calculator pop-up which
appears, and press Enter to activate the value and close the pop-up.
Note that the Pre Roll value is only displayed when the Pre Roll button is active
Note also that Pre Roll is disabled when auditioning Cuts within the main Cuts List, as part of the Append or Insert
procedures.
Saving Playlists
The Save button in the Playlist Edit window simply saves the Playlist under the same name. Pressing the Save button
on a Playlist which hasn’t been saved before will cause a keyboard to appear, in which the Playlist can be named before saving.
The Save As button allows the Playlist to be saved with a new name, leaving the Playlist on which it was based unchanged.
Press OK to close the Playlist Edit window and return to the previous screen. Pressing OK when your changes have
not been saved will activate the Save As function, inviting you to name and save the edited Playlist. To cancel your changes,
press OK and then simply cancel the keyboard pop-up which appears.
Note that new Playlists are always saved in the same folder as the one on which it is based. The Playlist location can be
altered via Samba Share. See ‘Uploading and Managing Audio Files for C-Play’ for details.
Note also that the Save, Save As and OK buttons can be used to save and close Playlists when displaying the main
Cuts List as well as when displaying the Playlist itself.

Solid State Logic C100 HDS Specifications

Power

console power	100-240 V AC
power consumption	300-700 W

DSP and Audio Processing

maximum input channels	256
second input path channels	512
utility busses	24 mono
aux busses	24 mono
dedicated ASG buses	16
dedicated PGM buses	12
delay modules	64 modules, 5.4 seconds each

Weight and Dimensions

max height	100.6 cm
weight (40 fader)	190 kg
height adjustment	0 to +1 cm
width (40 fader, flat end trim)	143.1 cm
max depth	92.6 cm
