Solid State Logic C100 HDS Software Update Manual

V4.2/6 Software Update
Page 19
Freeplay Mode
To enter Freeplay mode from V-Cart mode, use the 1 Player 2 button to select the correct Player, then
touch the Freeplay button towards the top right of the C-Play window. The Freeplay display will open,
and the Channel Information Display for the player’s fader strip will display a green Play button, as shown
to the right.
The main part of the Freeplay window consists of 16 Cut Triggers in four rows of four. There are 96 Triggers available to
each player, spread across six pages (Triggers 1-16, 17-32, 33-48, 49-64, 65-80 and 81-96) – you can scroll through the
pages of Triggers using the up and down arrows to the right of the Trigger area.
I
n basic operation, simply touch a Trigger in the Freeplay screen (with neither Trigger Setup nor Swap
selected) to start playback. Triggers go dark to indicate that they are playing.
Note that the Edit Trigger page defines what happens if a Trigger is touched while another Trigger is already playing.
The top and bottom of the Freeplay Trigger go green to indicate when there is one second remaining for each
Cut.
To pause all Triggers currently in playback, touch All Pause. To continue playback of all paused Triggers from the pause
location, touch All Pause again. To stop and reset all Triggers currently in playback, touch All Stop.
To swap the location of two Triggers, activate the Swap function, then touch each of the Triggers to be swapped.
Each Trigger displays the following information:
Note that if a Trigger has been set to loop continuously, the time and progress shown in the Trigger display indicate
progress through each loop. However, if a Trigger has been set to a specific number of loops, the Trigger display indicates
the progress through the complete set of loops, rather than each individual loop.
Trigger number Cut Name
Play time
(from start)
Time remaining
Progress bar Transport status
Switch
controls
between
Players
Switch to V-Cart Mode
Close C-Play
Touch a
Trigger
to trigger
its Cut
To edit a Trigger, activate Trigger Setup,
then touch the appropriate Trigger
Pause or Stop all active Triggers
Scroll up and down through Trigger pages
To swap the location of two
Triggers, activate Swap and touch
both Triggers to be swapped

Solid State Logic C100 HDS Specifications

Power

console power	100-240 V AC
power consumption	300-700 W

DSP and Audio Processing

maximum input channels	256
second input path channels	512
utility busses	24 mono
aux busses	24 mono
dedicated ASG buses	16
dedicated PGM buses	12
delay modules	64 modules, 5.4 seconds each

Weight and Dimensions

max height	100.6 cm
weight (40 fader)	190 kg
height adjustment	0 to +1 cm
width (40 fader, flat end trim)	143.1 cm
max depth	92.6 cm
