C100 HDS Software Update
Page 2
Firmware Update
C100 software V4.2/6 requires the following firmware to be running on the SSL PCI-E card and Madi Mezzanine cards.
T9960KF6 PCIE ROUTING & SPI 256CH
T
989RPLF MADI MEZZANINE (B-RIO) CONTROL V15.0 – (for 626989X2 and 626989X3)
T989PCU9 MADI MEZZANINE CONTROL UPPER V9.0 – (for 626989X4)
•
T989RPLF and T989PCU9 firmware together bring ‘Loop Redundancy’ functionality for consoles running V4.
Please check the version of firmware running on the SSL PCI-E card and Madi Mezzanine cards using the
firm command in
tclient and, if required, update the firmware to current revision.
• The UID numbers reported by firm will be as follows for the new firmware:
T9960KF6 UID :- 922
T989RPLF UID :- 1446
T989PCU9 UID :- 1447
If required, please contact your SSL representative for further instruction.
Network Connection Alteration
This software update requires a slight alteration to the Ethernet configuration in redundant setups. It is now necessary to
have the master machine connected to Net 4 on the console connector panel, with the slave connected to Net 1.
For a more detailed desription of Ethernet configuration, please refer to the latest version of the C100 HDS Installation
Guide, available from www.solidstatelogic.com.

Solid State Logic C100 HDS Specifications

Power

console power	100-240 V AC
power consumption	300-700 W

DSP and Audio Processing

maximum input channels	256
second input path channels	512
utility busses	24 mono
aux busses	24 mono
dedicated ASG buses	16
dedicated PGM buses	12
delay modules	64 modules, 5.4 seconds each

Weight and Dimensions

max height	100.6 cm
weight (40 fader)	190 kg
height adjustment	0 to +1 cm
width (40 fader, flat end trim)	143.1 cm
max depth	92.6 cm
