Solid State Logic C100 HDS Software Update Manual

C100 HDS Software Update
Page 26
BUG FIXES
• Occasional red file sync timeout message will no longer appear
• Pressing and holding the Insert IN key will now restore Insert normalling on Channels, ASG’s, PGM and Auxes
•
The PGM downmix for stereo PGM is now 0dB
• The ‘Sync Error’ message no longer incorrectly appears on large Morse systems when large amounts of routes
are made
• A project containing Morse IO as EXT inputs no longer causes a freeze on a subsequent project load

Solid State Logic C100 HDS Specifications

Power

console power	100-240 V AC
power consumption	300-700 W

DSP and Audio Processing

maximum input channels	256
second input path channels	512
utility busses	24 mono
aux busses	24 mono
dedicated ASG buses	16
dedicated PGM buses	12
delay modules	64 modules, 5.4 seconds each

Weight and Dimensions

max height	100.6 cm
weight (40 fader)	190 kg
height adjustment	0 to +1 cm
width (40 fader, flat end trim)	143.1 cm
max depth	92.6 cm
