Solid State Logic Fusion - Crosstalk and Stereo Matching

Fusion User Guide
Appendix B
22
Measurement Conditions Value
Crosstalk Analyser filters/BW: 22Hz to 20kHz (AES17). Generator
+24dBu into one channel, analyzer on the other channel
(generator connected but not active).
All circuits off / bypass
- 1 kHz
- 20Hz
- < -110dB, -115dB typical
- -110dB typical
Stereo Matching - All circuits off / Bypass
- Vintage Drive on
- < 0.01dB
- < 0.25dB typical
