Solid State Logic Fusion User Manual

Fusion User Guide
Appendix B
21
Appendix B - Analogue Specication
Audio Performance
Default test conditions (unless otherwise stated):
- Source impedance of Test Set: 50Ω
- Input impedance of Test Set: 100kΩ
- Reference frequency: 1kHz
- Reference level: 0dBu
- All unweighted measurements are specified as 22Hz to 22kHz band limited RMS and are expressed in units of dBu.
- The onset of clipping (for headroom measurements) should be taken as 1% THD.
- Measurements taken with Input and Output trim at center position.
- All levels are intended balanced.
Unless otherwise quoted all figures have a tolerance of ±0.5dB or 5%.
Measurement Conditions Value
Input Impedance 10kΩ
Output Impedance 75Ω
Max Input Level 1% THD 27.5 dBu
Max Output Level 1% THD 27.5 dBu
Frequency Response All circuits off
- 20Hz to 20kHz
- -3dB low rolloff
- -3dB high rolloff
- ±0.05dB
- < 5Hz
- > 180kHz
THD+Noise All circuits off
- +20dBu, 1kHz (filter 22Hz to 22kHz)
Bypass
- +20dBu, 1kHz (filter 22Hz to 22kHz)
Vintage Drive
- Indicator Off
- Indicator Green
- Indicator Orange
- Indicator Red
- < 0.005%, 0.0025% typical
- 0.0005% typical
- < 0.2% typical
- 0.2% to 0.5% typical
- 0.5% to 2% typical
- > 2% typical
CMRR - 20Hz
- 1kHz
- > 78dB, 85dB typical
- > 78dB, 88dB typical
Noise Analyser filters/BW: 22Hz to 20kHz (AES17).
- All circuits off
- Bypass
- Vintage Drive, mid Drive, mid Density
- < -86dBu, -91dBu typical
- -94dBu typical
- -75dBu typical
