Solid State Logic Fusion User Manual

Fusion User Guide
Hardware Overview
3
Hardware Overview
This section will detail the hardware features found on Fusion.
Front Panel
Rear Panel
Input Overload
LEDs
High-Pass Filter
Vintage Drive
Harmonic
Saturation Circuit
High Frequency
Compressor
Stereo Image
Circuit - Side Signal
Processing
Custom
Transformer
Circuit
Insert Point -
Switchable Pre/
Post EQ
Violet EQ
2-band Shelving
Filter
Input Trim
±12dB
Output
Trim
±12dB
Master
Meter
Bypass
Switch
Balanced Insert
Sends
IEC Power Inlet
and Switch
Balanced Insert
Returns
Fuse Operating
Voltage Selection
Balanced Inputs
Balanced Outputs
Warning! Check the fuse orientation matches your supply voltage.
Warning! The left-hand side of Fusion can become warm due to the
linear power supply. Take care when handling.

Solid State Logic Fusion Specifications

General

Brand	Solid State Logic
Model	Fusion
Category	Recording Equipment
Language	English
