SSL Live Installation Information
Connections - Key
*1 - Mains Power Connector
Connector Type - IEC 60320 - C13
*2 - MADI
BNC Co-axial MADI connections
Co-axial MADI
BNC connections to IEC 60169-8
Cables should be at least to Belden 1694F Low Loss Serial Digital Coax standard, fitted with high
quality BNC connections.
Cables runs between Console or Blacklight-MADI Concentrators and Stageboxes up to 75 meters.
Higher quality cable/connections can support up to 100 meters.
75 m Drum of correct cable - SSL Part Number 66DR07501
Specification for Belden cable can be found here:
edesk.belden.com/products/techdata/metric/pdf/1694F.pdf
Fibre MADI
Duplex SC multimode sockets
Fibre - Multimode 50/125 µm, maximum length <1000 m (quality cables, connections and no
intermediate connections)
*3a - Blacklight II
Redundant pair(s) of fibre connections. The pair consists of primary and redundant connections.
Connector Type - Neutrik opticalCON DUO for ruggedised applications (compatible with duplex LC
fibre connections for non-rugged applications).
Fibre - Multimode 50/125 µm, maximum length <300 m (quality cables, connections and no
intermediate connections)
Pre-terminated drums available from SSL in 150m (std) and 100m (to order) lengths.
150 m BL MM Fibre cable drum SSL Part No. 66DP15003
100 m BL MM Fibre cable drum SSL Part No. 66DP10003
Fibre - Singlemode (special order) 9/125 µm, maximum length <1 km (quality cables, connections
and no intermediate connections)
Pre-terminated drums available from SSL in 150m and 300m (both to order) lengths.
150 m BL SM Fibre cable drum SSL Part No. 66DP15004
300 m BL SM Fibre cable drum SSL Part No. 66DP30004
*3b - Blacklight II LC fibre
Redundant pair(s) of LC fibre connections. The pair consists of primary and redundant connections.
Connector Type - Duplex LC fibre connections for non-rugged applications.
Fibre - Multimode 50/125 µm, maximum length <300 m (quality cables, connections and no
intermediate connections)
www.solidstatelogic.com Page 29 of 43
