7
Primary Port A / Primary Port B
Each Pro Tools
®
HD port provides 32 input and output channels, regardless of sample rate.
MADI A / MADI B
The two MADI ports provide up to 64 input and output channels, depending on sample rate. Both MADI interfaces are fibre
optic using SC-type connectors; we offer a separate external MADI coaxial to optical converter solution to interface Delta-Link
MADI HD into coaxial systems.
USB
The USB interface can be used to control various settings of the Delta-Link MADI HD hardware and to update the internal
firmware. This interface is USB 1.0 compliant and uses a Style-A USB connector.
WordClock In
This input must be used to supply a clock reference signal to the Delta-Link MADI HD.
Power
The unit is powered by an internal, auto-switching power supply. The connector is an IEC 320 type.
