SOLINTEG ECA-B Series - Appendix; Technical Parameters

33
User Manual
ECA-B Series
7 Appendix
※ 7.1TechnicalParameters
Model ECA-S07K-BS0 ECA-S11K-BS0 ECA-S22K-BS0
GeneralInformation
Charging Mode Mode 3 (IEC 61851-1)
Input Rating
230±15%Vac, 50/60Hz,
single-phase, L+N+PE
400±15%Vac,
50/60Hz, three-phase,
L1+L2+L3+N+PE
400±15%Vac,
50/60Hz, three-phase,
L1+L2+L3+N+PE
Output Rating
7kW/ max. 32A 11kW/ max. 16A 22kW/max. 32A
Grid Type TN-S, TN-C-S, TT, IT(L1+L2 230Vac Single phase)
Charging Inteace
IEC 62196-2 Type 2 tethered plug (Case C)
Metering Onboard metering chip
Power Consumption 4W
Residual Current Protection DC 6mA
Protection
Overcurrent, Oveoltage, Undeoltage, Residual current, Over temperature,
Grounding fault, Integrated surge protection
UserInteace
Status Indication LED indicator
Button & Switch
Emergency button
User Authentication RFID card, App
RFID Reader ISO 14443 A
Communication
Network Inteace RS485
Protocol (EVSE&EV) Control pilot
Environmental
Operating Temperature -30℃ to 50℃
Storage Temperature -40°C ~ +55°C
Humidity 5% to 95% no condensation
Altitude ≤3000m above sea level
