Safety Instruction



•Please follow the instructions in this chapter, and familiarize yourself with all safety in-

structions and regulations.

•The installer must always ensure that the installation of the charger complies with local

regulations.

•The installation, maintenance and repair of this product may only be performed by a

trained electrician.

•The electricity transmission licensee shall be consulted prior to the commencement of

any eahworks (for the purpose of installing structure, cables, eahing system, etc.) to

prevent damage to any underground electricity cables under the management of the elec-

tricity transmission licensee.

※ 1.1Safety

1.1.1 General Rules of Safety

•Please prevent incorrect operation steps, practices or execution.

•Improper installation or maintenance may be dangerous to users.

WARNING: RISK OF PERSONAL INJURY

CAUTION: RISK OF DAMAGE TO THE EQUIPMENT

•This product is designed and tested in accordance with international standards.

•This product can only be limited to its design purpose.

•All parts of the product cannot be repaired by the user. Do not attempt to repair the

charger yourself.

•Do not install this product in potentially explosive environments, areas with high electro-

magnetic radiation and areas susceptible to ooding.

•Ensure that this product is used only under proper operating conditions.

•Do not use adapters or conveing adapters.

•Do not use cable extension kits.

•Make sure the power cord connected to the charger is routed from the dedicated Type

A RCBO or MCB+ Type A RCCB in the distribution box. The Type A RCBO or MCB+ Type A

RCCB must match the capacity of the charging cable used.

•Please store this product in a d environment, the storage temperature must be be-

tween -40°C ~ +55°C.
