User Manual

ECA-B Series

4.2.3 Connection with MHT/MHS Series

EV charger and batte use communication po of the inveer in common, and the general

wiring diagram among the inveer, EV charger and the batte is shown as below:

Connect inveer BMS po to “IN” po of waterproof connector via network cable labeled

with “INV”.

Connect communication po of batte to “OUT” po of waterproof connector via network

cable labeled with “BMS”.

Connect RS485 communication po of EV charger to “OUT” po of waterproof connector

via network cable labeled with “EVC”.

Please note that RS485 A and RS485 B can not be connected reversely which might lead to

communication failure.

BMS

INV
