User Manual
6.7.8 STD Mode Settings UL-480-18
1. Working Mode Set
2. Power Rate Limit
3. Freq Derate Set
4. 10mins Voltage Set
5. Power Priority
6. Initial Settings
7. Voltage PCC Set
8. Freq-Watt
Selecting “STD Mode. Settings” displays the sub-menu shown below:
This section is applicable to maintenance personnel only.
Solis US version inverters have Seven working modes:
1. NULL
2. Volt-watt
3. Volt-Var
4. Fixed-PF
5. Reac-power
6. Power-PF
7. VgWatt-UL
Based on UL1741SA, working mode 1,3,4,7 can be used by grid operator.
6.7.8.1 Working Mode Set
6.7.8.1.1 With UL Standard selected
There are TWO situations with different grid standards selected.
NOTE
The following modes are for "UL-480V-18”.
6. Normal operation
46
NOTE
To Next Page
