User Manual
3.3.1 Wall mounting
3. Installation
13
1. Use the suitable mounting screws to attach the bracket on the wall.
Figure 3.8
2. Take off the Protective cover on the back of AC wiring box.
Figure 3.7 Inverter wall mounting
Bracket
Suitable mounting screws
Torque:22.1-25.8 ft.lbs
3. Take off the Protective cover in the side of inverter.
Figure 3.9
