User Manual
3. Installation
14
4. Use the Connecting plate with screws to fix the AC wiring box on the bracket.
Figure 3.10
5. Lift the inverter and hang it on the bracket, and slide down to make sure they match
perfectly. Finally push the inverter to match the AC wiring box.
Figure 3.11
