Solo 433 - Technical Specifications

Technical Specifications
ENGLISH 7
2. Technical Specifications
Engine type SOLO single cylinder two stroke engine
Engine capacity cm
3
25 ccm
Bore / stroke mm 33 / 30
Engine performance kW at rpm 0.75 / 6500
Medium idling speed rpm 2800
Max. Admissible engine speed rpm 6700
Fuel tank capacity l 0,3
Fuel mix ratio:
with "CASTROL SUPER TT"
with other two stroke oils
1:50 (2%)
1:25 (4%)
Carburettor All-position diaphragm carburettor with
primer and integrated fuel pump
Air filter Compressed fibre filter with foam material
insert
Ignition Electronically controlled magneto ignition,
maintenance free
Capacity of liquid tank l 24
Nominal volume l 23
Liquid inlet filter mesh size mm 0,65
Residual liquid volume in tank after
machine stops regular spray output ml
< 200
Operating pressure bar 5 - 30
Output volume with standard nozzle l/min
at 5 bar operating pressure
at 10 bar operating pressure
at 20 bar operating pressure
at 30 bar operating pressure
0,7
1,2
1,7
2,0
Spray Wand Material
Length in mm
Connecting thread
Steel tube
50
19 windings/inch
Spray hose Length in mm
Pressure resistant to bar
128
> 50
Spray nozzle, standard Double flat spray
Work site related L
Peg
to EN ISO 11200 idling / full speed
dB(A) 82
Sound pressure level L
Weg
to EN ISO 3744
measured / guaranteed 95% dB(A) 94,2 / 95
Weighted average of acceleration to ISO 7916 handle at
max. engine speed m/s
2
< 2,0
Total weight (ready to go - empty liquid tank) kg 8,3
Dimensions without spray wand and spray hose mm Height: 630 / Width: 440 / Depth: 320
