Functions of the Relays and Analogue and Digital Inputs and Outputs
SP25-55_User Manual_B8_EN_2012-11-06 27/32
Parameter 299: Function of analogue output 2
Menu: Output control
Unit: ---
Resolution: ---
Default setting: 0
Password level: 1
Possible settings for analogue outputs 1 and 2:
Value = 0 Set output to 0 V
Value = 1 Set output to DC voltage (UDC). 400 V correspond to 4.00 V
Value = 2 Set output to DC current (IDC). 5.00 A correspond to 5.00 V *
Value = 3 Set output to DC current (IDC). 12.00 A correspond to 6.00 V
Value = 4 Set output to AC current (IAC). 5.00 A correspond to 5.00 V *
Value = 5 Set output to AC current (IAC). 12.00 A correspond to 6.00 V *
Value = 6 Set output to AC current (IAC). 22.00 A correspond to 5.50 V
Value = 7 Set output to AC power fed to grid (PAC). 500 W correspond to 5.00 V *
Value = 8 Set output to AC power fed to grid (PAC). 1,200 W correspond to 6.00 V *
Value = 9 Set output to AC power fed to grid (PAC). 3,000 W correspond to 7.50 V *
Value = 10 Set output to AC power fed to grid (PAC). 5,000 W correspond to 5.00 V
Value = 11 Set output to DC power (PDC). 500 W correspond to 5.00 V *
Value = 12 Set output to DC power (PDC). 1,200 W correspond to 6.00 V *
Value = 13 Set output to DC power (PDC). 3,000 W correspond to 7.50 V *
Value = 14 Set output to DC power (PDC). 5,000 W correspond to 5.00 V
Value = 15 Set output to temperature of inverter. 50°C correspond to 5.00 V
Value = 16 Set output to temperature of modules. 50°C correspond to 5.00 V, but only above 0°C
Value = 17 Set output to external temperature. 50°C correspond to 5.00 V, but only above 0°C
Value = 18 Set output to insolation. 800 W/m² correspond to 8.00 V *
Value = 19 Set output to insolation. 1,200 W/m² correspond to 6.00 V
Value = 20 Set output to PAC of installation. 8,000 W correspond to 8.00 V *
Value = 21 Set output to PAC of installation. 55,000 W correspond to 5.50 V
* These values may overflow when the upper limit is reached.
The connector pin assignments are as follows:
X4, pin 1 Analogue output 1, 0 to 10 V
X4, pin 2 Analogue output 2, 0 to 10 V
X4, pin 14 Ground reference for analogue inputs
17.5 Digital inputs
The inverter is equipped with 2 voltage-free (isolated) digital inputs. Their level can be displayed by
means of parameters 35 and 36.
Parameter 35: Digital input 1
Menu: Actal values/Sensor
Unit: ---
Resolution: 1
