- 6 -
Figure 7 Back View Indication
Figure 8 Input & Output defines
Input Pins: The input pins can be used for 2-way external sensor input. For example,
you may connect a Person Infrared Sensor (PIR) to it for motion detection. When
CF Card Socket
Reset button
Input & Output Pins
RJ45 Ethernet Socket
DC 5V Input Socket
Output Pins
Relay: Normally Open
Digit Input Pins
Output
A B
Input Common Input
1 2
1 2 3 4 5
