Sonim XP5plus User Manual

7
INSERTING THE MEMORY CARD
Insert the memory card to add extra storage space for
your music, pictures, videos, and more.
1. SLIDE THE SILVER CLIP
Slide (push forward)
and lift the silver clip
over the designated
slot located beside
the SIM card slot (as
shown in the figure).
2. PLACE THE
MEMORY CARD
Place the memory
card in the designated
slot and close the
silver clip (as shown in
the figure).
3. CLOSE THE
BATTERY COVER
Use Sonim provided
screwdriver and
tighten the screw on
the back cover.
GETTING STARTED
MEMORY CARD IS OPTIONAL AND SOLD
SEPARATELY.

Sonim XP5plus Specifications

General

Display Size	2.8 inches
Operating System	Android 11
RAM	2 GB
Internal Storage	16 GB
Rear Camera	5 MP
Waterproof	IP68
MIL-STD-810H	Yes
SIM	Single SIM (Nano-SIM) or Dual SIM (Nano-SIM, dual stand-by)
Screen Type	TFT
Resolution	240 x 320 pixels
CPU	Quad-core 1.3 GHz Cortex-A53
GPU	Adreno 308
Loudspeaker	Yes
3.5mm jack	Yes
NFC	Yes
Radio	FM radio
USB	USB Type-C 2.0
Charging	Fast charging 18W
2G bands	GSM 850 / 900 / 1800 / 1900
3G bands	HSDPA 850 / 900 / 1700(AWS) / 1900 / 2100
Speed	HSPA, LTE
Push-to-Talk	Yes
Expandable Storage	microSD
Drop-to-concrete resistance	Up to 1.5m
WLAN	Wi-Fi 802.11 b/g/n, hotspot
Bluetooth	4.2, A2DP
GPS	Yes, with A-GPS, GLONASS
Sensors	Accelerometer, proximity
Chipset	Qualcomm QM215
4G bands	1, 2, 3, 4, 5, 7, 8, 12, 13, 17, 20, 25, 26, 28, 38, 39, 40, 41, 66
