77
Using the viewing functions
Enlarging images
An image can be enlarged for closer examination.
1 Press the (Enlarge) button in single-image (or index) playback mode.
The center of the image is enlarged.
You can scale up or down with the (Enlarge) button or the (Reduce) button.
2 Select the portion you want to enlarge with v/V/b/B on the controller.
You can select the image with the control dial.
Each time you press the center of the controller, the screen changes between the enlarged screen and
the whole screen.
3 Press the (Playback) button so that enlarged playback is canceled and the screen returns to
single-image (or index) playback mode.
The scaling range is as follows. (The scale is not displayed)
Pressing the (Display) button clears the indications on the screen during enlarged playback.
Image size Scaling range
L:10M Approx. ×1.1 – ×12
M:5.6M Approx. ×1.1 – ×9
S:2.5M Approx. ×1.1 – ×6
(Enlarge) button
(Reduce) button
(Playback) button
(Display) button
Controller
The portion to be
enlarged if the center
button is pressed
The map of the enlarged portion

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Sony a (alpha) DSLR-A100 and is the answer not in the manual?

Sony a (alpha) DSLR-A100 Specifications

General IconGeneral
Sensor TypeCCD
Sensor Size23.6 x 15.8 mm
Effective Pixels10.2 MP
Autofocus Points9
Screen Size2.5 inches
Viewfinder TypeOptical (pentamirror)
Weight638 g (body only)
Shutter Speed30 - 1/4000 sec
Continuous Shooting3 fps
Image ProcessorBIONZ
Video RecordingNo
Dimensions133 x 95 x 71 mm
ISO SensitivityISO 100-1600
Storage TypesCompactFlash (Type I or II)
Battery TypeNP-FM55H
Lens MountSony A-mount
