Sony BDP-S301 - Reassembly; Upper Case; Tray Cover Assy

2-5
2-2. REASSEMBLY
•This set can be assembled in the order shown below.
2-2-1. UPPER CASE
3 tapping screw
3 tapping screw
2 three screws
1 upper case
2-2-2. TRAY COVER ASSY
1 Insert a clip in the hole of a drive
and open a tray.
4 two claws
3 tray cover assy
2
