2-7
2-2-5. FL-176 BOARD, FR-271 BOARD
2-2-6. DC FAN
1 FL-176 board
2 two screws
3 FR-271 board
4 two screws
5 flexible flat cable
(FLR-011)
3 connector
1 DC fan
2 two screws
