6-6
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
AU-258 FL-176
R140 1-208-774-11 METAL CHIP 470 0.5% 1/10W
R141 1-208-774-11 METAL CHIP 470 0.5% 1/10W
R142 1-208-774-11 METAL CHIP 470 0.5% 1/10W
R143 1-208-822-11 METAL CHIP 47K 0.5% 1/10W
R144 1-208-822-11 METAL CHIP 47K 0.5% 1/10W
R145 1-208-822-11 METAL CHIP 47K 0.5% 1/10W
R146 1-208-822-11 METAL CHIP 47K 0.5% 1/10W
R149 1-208-822-11 METAL CHIP 47K 0.5% 1/10W
R150 1-208-822-11 METAL CHIP 47K 0.5% 1/10W
R153 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R154 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R155 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R156 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R157 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R158 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R161 1-216-845-11 METAL CHIP 100K 5% 1/10W
R162 1-216-845-11 METAL CHIP 100K 5% 1/10W
R163 1-216-845-11 METAL CHIP 100K 5% 1/10W
R165 1-208-774-11 METAL CHIP 470 0.5% 1/10W
R166 1-208-774-11 METAL CHIP 470 0.5% 1/10W
R167 1-208-774-11 METAL CHIP 470 0.5% 1/10W
R168 1-208-774-11 METAL CHIP 470 0.5% 1/10W
R169 1-208-774-11 METAL CHIP 470 0.5% 1/10W
R170 1-208-774-11 METAL CHIP 470 0.5% 1/10W
R171 1-208-774-11 METAL CHIP 470 0.5% 1/10W
R173 1-208-774-11 METAL CHIP 470 0.5% 1/10W
R175 1-216-864-11 SHORT CHIP 0
R176 1-216-864-11 SHORT CHIP 0
R177 1-216-864-11 SHORT CHIP 0
R178 1-216-809-11 METAL CHIP 100 5% 1/10W
FL-176 BOARD, COMPLETE
(Ref. No. 2000 Series)
**********************
< CAPACITOR >
C101 1-125-972-91 ELECT 100uF 20% 16V
C102 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C105 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C108 1-125-972-91 ELECT 100uF 20% 16V
C113 1-163-021-91 CERAMIC CHIP 0.01uF 10% 50V
C115 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C117 1-107-715-11 ELECT 22uF 20% 50V
C118 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V
C119 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V
C120 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V
C123 1-107-726-91 CERAMIC CHIP 0.01uF 10% 16V
C124 1-107-726-91 CERAMIC CHIP 0.01uF 10% 16V
< CONNECTOR >
CN100 1-770-658-11 CONNECTOR, FFC/FPC 30P
CN101 1-779-279-11 CONNECTOR, FFC (LIF (NON-ZIF)) 11P
< DIODE >
D100 8-719-941-86 DIODE DAN202U
D101 8-719-988-61 DIODE 1SS355TE-17
D102 8-719-988-61 DIODE 1SS355TE-17
D103 8-719-988-61 DIODE 1SS355TE-17
D104 8-719-988-61 DIODE 1SS355TE-17
D105 8-719-036-94 DIODE RD5.6SB-T1
< FUSE >
0F100 1-576-863-21 FUSE 0.5A 32V
< FERRITE BEAD >
FB001 1-414-226-21 INDUCTOR, FERRITE BEAD
FB002 1-414-226-21 INDUCTOR, FERRITE BEAD
FB003 1-414-226-21 INDUCTOR, FERRITE BEAD
FB004 1-414-226-21 INDUCTOR, FERRITE BEAD
< IC >
IC100 8-759-643-83 IC uPD16315GB-3BS
< COIL >
L102 1-414-743-21 INDUCTOR 47uH
< FLUORESCENT INDICATOR TUBE >
ND100 1-519-958-11 INDICATOR TUBE, FLUORESCENT
< TRANSISTOR >
Q100 8-729-027-46 TRANSISTOR DTC114YKA-T146
Q101 8-729-901-00 TRANSISTOR DTC124EK
Q102 8-729-901-00 TRANSISTOR DTC124EK
Q103 6-551-382-01 TRANSISTOR RSS040P03FD5TB
Q104 8-729-901-88 TRANSISTOR 2SC2411K-CR
Q105 8-729-901-88 TRANSISTOR 2SC2411K-CR
< RESISTOR >
R100 1-216-864-11 SHORT CHIP 0
R101 1-216-833-11 METAL CHIP 10K 5% 1/10W
R102 1-216-864-11 SHORT CHIP 0
R103 1-216-837-11 METAL CHIP 22K 5% 1/10W
R104 1-216-837-11 METAL CHIP 22K 5% 1/10W
R105 1-216-837-11 METAL CHIP 22K 5% 1/10W
R106 1-216-805-11 METAL CHIP 47 5% 1/10W
R107 1-216-805-11 METAL CHIP 47 5% 1/10W
R108 1-216-805-11 METAL CHIP 47 5% 1/10W
R109 1-216-864-11 SHORT CHIP 0
R110 1-216-824-11 METAL CHIP 1.8K 5% 1/10W
R111 1-216-845-11 METAL CHIP 100K 5% 1/10W
R112 1-216-838-11 METAL CHIP 27K 5% 1/10W
R113 1-216-833-11 METAL CHIP 10K 5% 1/10W
R117 1-216-833-11 METAL CHIP 10K 5% 1/10W
R118 1-216-832-11 METAL CHIP 8.2K 5% 1/10W
R119 1-216-834-11 METAL CHIP 12K 5% 1/10W
R120 1-216-833-11 METAL CHIP 10K 5% 1/10W
R121 1-216-824-11 METAL CHIP 1.8K 5% 1/10W
R122 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R123 1-216-832-11 METAL CHIP 8.2K 5% 1/10W
R124 1-216-834-11 METAL CHIP 12K 5% 1/10W
R125 1-216-834-11 METAL CHIP 12K 5% 1/10W
R126 1-216-839-11 METAL CHIP 33K 5% 1/10W
The components identified by
mark 0 or dotted line with
mark 0 are critical for safety.
Replace only with part number
specified.
Les composants identifiés par une
marque 0 sont critiques pour la
sécurité.
Ne les remplacer que par une pièce
portant le numéro spécifié.
