Sony BDP-S5000ES - System Specifications; Inputs and Outputs; General Operating Conditions; Specifications

71
Additional Information
Specifications
System
Laser: Semiconductor laser
Inputs and outputs
(Jack name:
Jack type/Output level/Load impedance)
AUDIO OUT L/R:
Phono jack/2 Vrms/10 kilohms
DIGITAL OUT (OPTICAL):
Optical output jack/–18 dBm
(wave length 660 nm)
DIGITAL OUT (COAXIAL):
Phono jack/0.5 Vp-p/75 ohms
MULTI CHANNEL OUTPUT:
Phono jack/2 Vrms/10 kilohms
HDMI OUT:
HDMI 19-pin standard connector
COMPONENT VIDEO OUT
(Y, P
B, PR):
Phono jack/Y: 1.0 Vp-p/
P
B, PR: 0.7 Vp-p/75 ohms
VIDEO OUT VIDEO:
Phono jack/1.0 Vp-p/75 ohms
VIDEO OUT S VIDEO:
4-pin mini DIN/
Y: 1.0 Vp-p, C: 0.286 Vp-p/75 ohms
LAN (100):
100BASE-TX Terminal
EXT:
External memory slot (For connecting the
external memory)
DC output: 5 V 500 mA Max
CONTROL S IN/IR IN:
Mini jack
RS-232C port:
D-sub 9-pin
General
Power requirements:
120 V AC, 60 Hz
Power consumption:
42 W
Dimensions (approx.):
430 mm × 365 mm × 125 mm
(17 in. × 14
3
/
8
in. × 5 in.)
(width/depth/height) incl. projecting parts
Mass (approx.):
10 kg (22 lb)
Operating temperature:
5ºC to 35ºC (41°F to 95°F)
Operating humidity:
25 % to 80 %
Supplied accessories
See page 13.
Specifications and design are subject to
change without notice.
