Identifying the parts
$∞ Lighting aperture
$§ EJECT switch (p. 11)
$¶ LANC l control jack
l stands for Local Application Control
Bus System. The l control jack is used
for controlling the tape transport of
video equipment and peripherals
connected to it. This jack has the same
function as the jack indicated as
CONTROL L or REMOTE.
$• Cassette compartment (p. 11)
$ª Grip strap (p. 19)
%º RFU DC OUT (RFU adaptor DC output)
jack (p. 66)
%¡ S VIDEO jack (p. 66)
%™ VIDEO/AUDIO jacks (p. 66)
%£ MIC jack (PLUG IN POWER)
Connect an external microphone (not
supplied). This jack also accepts a “plug-
in-power” microphone.
%¢ Camera recording/battery lamp (p. 12)
%∞ LASER LINK emitter (p. 67)/NightShot
Light emitter (p. 39)
%§ Remote sensor (p. 103)
Aim the Remote Commander here for
remote control.
%¶ Microphone
%• 2 (headphones) jack (p. 23)
