63
CDP-CX355
8-10. Optical Pick-up Section (BU-K1BD45)
Ref. No. Part No. Description Remarks
451 1-792-024-11 WIRE (FLAT TYPE) (16 CORE)
452 A-4727-737-A BD BOARD, COMPLETE
* 453 4-992-054-01 RUBBER, VIBRATION PROOF
0 454 A-3328-818-A OPTICAL PICK-UP KSM-213BFN/C2NP
#2 7-621-772-21 SCREW +B 2X5
452
453
453
454
451
#2
The components identified by
mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number
specified.
Les composants identifiés par
une marque 0 sont critiques
pour la sécurité.
Ne les remplacer que par une
pièce portant le numéro spécifié.
