Sony CDP-CX355 - Page 70

Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
70
CDP-CX355
R545 1-249-382-11 CARBON 1.2 5% 1/6W F
R546 1-249-393-11 CARBON 10 5% 1/4W F
R547 1-249-431-11 CARBON 15K 5% 1/4W
R550 1-249-421-11 CARBON 2.2K 5% 1/4W F
R551 1-249-441-11 CARBON 100K 5% 1/4W
R552 1-249-417-11 CARBON 1K 5% 1/4W F
R553 1-249-441-11 CARBON 100K 5% 1/4W
R554 1-247-883-00 CARBON 150K 5% 1/4W
R555 1-249-425-11 CARBON 4.7K 5% 1/4W F
R556 1-249-382-11 CARBON 1.2 5% 1/6W F
R557 1-249-382-11 CARBON 1.2 5% 1/6W F
R558 1-247-807-31 CARBON 100 5% 1/4W
R559 1-249-419-11 CARBON 1.5K 5% 1/4W F
R560 1-249-421-11 CARBON 2.2K 5% 1/4W F
R561 1-249-441-11 CARBON 100K 5% 1/4W
R562 1-249-417-11 CARBON 1K 5% 1/4W F
R563 1-249-441-11 CARBON 100K 5% 1/4W
R564 1-247-883-00 CARBON 150K 5% 1/4W
R565 1-249-425-11 CARBON 4.7K 5% 1/4W F
R566 1-249-382-11 CARBON 1.2 5% 1/6W F
R567 1-249-382-11 CARBON 1.2 5% 1/6W F
R569 1-249-419-11 CARBON 1.5K 5% 1/4W F
R570 1-249-425-11 CARBON 4.7K 5% 1/4W F
R571 1-249-425-11 CARBON 4.7K 5% 1/4W F
R591 1-247-807-31 CARBON 100 5% 1/4W
R592 1-247-807-31 CARBON 100 5% 1/4W
R593 1-247-807-31 CARBON 100 5% 1/4W
R594 1-247-807-31 CARBON 100 5% 1/4W
R595 1-247-807-31 CARBON 100 5% 1/4W
R720 1-249-429-11 CARBON 10K 5% 1/4W
R730 1-249-429-11 CARBON 10K 5% 1/4W
R740 1-249-429-11 CARBON 10K 5% 1/4W
R750 1-249-429-11 CARBON 10K 5% 1/4W
R760 1-249-429-11 CARBON 10K 5% 1/4W
R940 1-249-425-11 CARBON 4.7K 5% 1/4W F
R941 1-249-425-11 CARBON 4.7K 5% 1/4W F
< VARIABLE RESISTOR >
RV501 1-241-786-11 RES, ADJ, CARBON 22K
< VIBRATOR >
X501 1-579-175-11 VIBRATOR, CERAMIC (10MHz)
**************************************************************
1-672-638-11 POWER BOARD
*************
< CAPACITOR >
0 C901 1-113-925-11 CERAMIC 0.01uF 20.00% 250V
C910 1-161-494-00 CERAMIC 0.022uF 25V
C911 1-126-767-11 ELECT 1000uF 20.00% 16V
C912 1-126-767-11 ELECT 1000uF 20.00% 16V
C920 1-161-494-00 CERAMIC 0.022uF 25V
C921 1-126-767-11 ELECT 1000uF 20.00% 16V
C922 1-126-767-11 ELECT 1000uF 20.00% 16V
C932 1-126-936-11 ELECT 3300uF 20.00% 16V
C937 1-126-960-11 ELECT 1uF 20.00% 50V
< CONNECTOR >
* CN991 1-580-230-11 PIN, CONNECTOR (PC BOARD) 2P
< DIODE >
D901 8-719-911-19 DIODE 1SS133T-72
D910 8-719-024-99 DIODE 11ES2-NTA2B
D911 8-719-024-99 DIODE 11ES2-NTA2B
D912 8-719-024-99 DIODE 11ES2-NTA2B
D913 8-719-024-99 DIODE 11ES2-NTA2B
D920 8-719-200-77 DIODE 10E2N-TA2B
D921 8-719-200-77 DIODE 10E2N-TA2B
D922 8-719-200-77 DIODE 10E2N-TA2B
D923 8-719-200-77 DIODE 10E2N-TA2B
D930 8-719-911-19 DIODE 1SS133T-72
D931 8-719-911-19 DIODE 1SS133T-72
D932 8-719-210-21 DIODE 11EQS04-TA2B
D933 8-719-210-21 DIODE 11EQS04-TA2B
D934 8-719-210-21 DIODE 11EQS04-TA2B
D935 8-719-210-21 DIODE 11EQS04-TA2B
D939 8-719-911-19 DIODE 1SS133T-72
< GROUND TERMINAL >
EB1 1-537-770-21 TERMINAL BOARD, GROUND
EB2 1-537-770-21 TERMINAL BOARD, GROUND
< LINE FILTER >
0 L901 1-424-485-11 FILTER, LINE
< TRANSISTOR >
Q930 8-729-620-05 TRANSISTOR 2SC2603TP-EF
< RESISTOR >
R930 1-249-429-11 CARBON 10K 5% 1/4W
R931 1-249-421-11 CARBON 2.2K 5% 1/4W F
R933 1-249-429-11 CARBON 10K 5% 1/4W
R934 1-249-417-11 CARBON 1K 5% 1/4W F
< RELAY >
0 RY901 1-755-299-11 RELAY
**************************************************************
MAIN POWER
The components identified by
mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number
specified.
Les composants identifiés par
une marque 0 sont critiques
pour la sécurité.
Ne les remplacer que par une
pièce portant le numéro spécifié.
