Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
MAIN
R661 1-216-065-00 METAL CHIP 4.7K 5% 1/10W
(EXCEPT UK)
< RELAY >
RY301 1-515-803-11 RELAY
< TRANSFORMER >
T201 1-409-594-11 COIL (WITH CORE) (AEP, UK)
< VIBRATOR >
X321 1-760-955-11 VIBRATOR, CRYSTAL (45MHz)
************************************************************
* A-4699-751-A POWER BOARD, COMPLETE (EXCEPT UK)
* A-4699-756-A POWER BOARD, COMPLETE (UK)
***********************
* 4-363-146-00 HEAT SINK, V.OUT
7-685-871-01 SCREW +BVTT 3X6 (S)
< CAPACITOR >
C901 1-124-704-11 ELECT 3300uF 20% 25V
C902 1-124-704-11 ELECT 3300uF 20% 25V
C903 1-124-563-11 ELECT 2200uF 20% 25V
C904 1-124-563-11 ELECT 2200uF 20% 25V
C905 1-124-689-11 ELECT 1000uF 20% 16V
C906 1-101-006-00 FILM 0.047uF 50V
C907 1-101-006-00 FILM 0.047uF 50V
C908 1-101-006-00 FILM 0.047uF 50V
C909 1-102-129-00 FILM 0.01uF 10% 50V
C910 1-162-290-31 CERAMIC 470PF 10% 50V
C911 1-126-017-11 ELECT 6800uF 20% 16V
C912 1-128-201-11 ELECT 100uF 20% 63V
C913 1-162-294-31 CERAMIC 0.001uF 10% 50V
C914 1-126-162-11 ELECT 3.3uF 20% 50V
C915 1-128-200-11 ELECT 47uF 20% 63V
C921 1-124-556-11 ELECT 2200uF 20% 16V
(EXCEPT UK)
C922 1-126-059-11 ELECT 10uF 20% 50V
(EXCEPT UK)
C923 1-162-294-31 CERAMIC 0.001uF 10% 50V
C951 1-126-063-11 ELECT 100uF 20% 63V
C952 1-128-198-11 ELECT 22uF 20% 63V
C953 1-126-059-11 ELECT 10uF 20% 50V
C954 1-129-702-00 FILM 0.001uF 5% 630V
< CONNECTOR >
CN251 1-564-506-11 PLUG, CONNECTOR 3P
CN901 1-691-771-11 PLUG (MICRO CONNECTOR) 9P
CN902 1-691-767-11 PLUG (MICRO CONNECTOR) 5P
CN903 1-564-505-11 PLUG, CONNECTOR 2P
CN951 1-691-768-11 PLUG (MICRO CONNECTOR) 6P
< DIODE >
D901 8-719-210-21 DIODE 11EQS04
D902 8-719-210-21 DIODE 11EQS04
D903 8-719-210-21 DIODE 11EQS04
D904 8-719-210-21 DIODE 11EQS04
D905 8-719-210-21 DIODE 11EQS04
D907 8-719-210-21 DIODE 11EQS04
D911 8-719-210-21 DIODE 11EQS04
D912 8-719-210-21 DIODE 11EQS04
D913 8-719-210-21 DIODE 11EQS04
D914 8-719-210-21 DIODE 11EQS04
D921 8-719-987-63 DIODE 1N4148M (EXCEPT UK)
D922 8-719-114-30 DIODE RD5.1JS-B2 (EXCEPT UK)
D923 8-719-987-63 DIODE 1N4148M (EXCEPT UK)
D924 8-719-987-63 DIODE 1N4148M (EXCEPT UK)
D925 8-719-987-63 DIODE 1N4148M (EXCEPT UK)
D951 8-719-200-82 DIODE 11ES2
D952 8-719-113-76 DIODE RD27ES-T2B2
D953 8-719-110-04 DIODE RD7.5ES-B3
< GROUND TERMINAL >
EB901 1-537-770-21 TERMINAL BOARD, GROUND
EB902 1-537-770-21 TERMINAL BOARD, GROUND
< IC >
IC901 8-759-604-86 IC M5F7807L
IC902 8-759-604-90 IC M5F7907L
IC903 8-759-231-53 IC TA7805S
IC911 8-759-231-53 IC TA7805S
IC912 8-759-636-16 IC M51957AL
IC913 8-759-604-86 IC M5F7807L
< TRANSISTOR >
Q951 8-729-140-97 TRANSISTOR 2SB734-34
< RESISTOR >
R911 1-249-436-11 CARBON 39K 5% 1/4W
R912 1-249-431-11 CARBON 15K 5% 1/4W
R913 1-247-843-11 CARBON 3.3K 5% 1/4W
R921 1-249-413-11 CARBON 470 5% 1/4W
(EXCEPT UK)
R922 1-249-417-11 CARBON 1K 5% 1/4W
(EXCEPT UK)
! R951 1-212-869-00 FUSIBLE 33 5% 1/4W F
R952 1-249-429-11 CARBON 10K 5% 1/4W
R953 1-249-435-11 CARBON 33K 5% 1/4W
************************************************************
The components identified by
mark ! or dotted line with
mark ! are critical for safety.
Replace only with part number
specified.
Les composants identifiés par une
marque ! sont critiques pour la
sécurité.
Ne les remplacer que par une pièce
portant le neméro spécifié.
POWER
