– 32 –
MAIN
C902 1-126-768-11 ELECT 2200uF 20% 16V
C903 1-128-576-11 ELECT 100uF 20% 63V
C904 1-101-006-00 CERAMIC 0.047uF 50V
(CND,E,AUS,CH)
C904 1-161-494-00 CERAMIC 0.022uF 25V
(AEP,UK,G,EE)
C905 1-101-006-00 CERAMIC 0.047uF 50V
(CND,E,AUS,CH)
C905 1-161-494-00 CERAMIC 0.022uF 25V
(AEP,UK,G,EE)
C906 1-101-006-00 CERAMIC 0.047uF 50V
(CND,E,AUS,CH)
C906 1-164-159-21 CERAMIC 0.1uF 50V
(AEP,UK,G,EE)
C907 1-101-006-00 CERAMIC 0.047uF 50V
(CND,E,AUS,CH)
C907 1-164-159-21 CERAMIC 0.1uF 50V
(AEP,UK,G,EE)
C908 1-101-006-00 CERAMIC 0.047uF 50V
(CND,E,AUS,CH)
C908 1-164-159-21 CERAMIC 0.1uF 50V
(AEP,UK,G,EE)
< CONNECTOR >
* CN201 1-568-839-11 SOCKET, CONNECTOR 23P
CN202 1-568-838-11 SOCKET, CONNECTOR 21P
CN901 1-580-230-11 PIN, CONNECTOR (PC BOARD) 2P (AEP,UK,G,EE)
< DIODE >
D400 8-719-982-22 DIODE MTZJ-30D
D401 8-719-991-33 DIODE 1SS133T-77
D402 8-719-109-97 DIODE RD6.8ES-B2
D403 8-719-010-34 DIODE UZ-4.7BSC
D701 8-719-991-33 DIODE 1SS133T-77
D702 8-719-991-33 DIODE 1SS133T-77
D703 8-719-991-33 DIODE 1SS133T-77
D704 8-719-991-33 DIODE 1SS133T-77
D705 8-719-991-33 DIODE 1SS133T-77
D706 8-719-991-33 DIODE 1SS133T-77 (AEP,UK,G,EE)
D707 8-719-991-33 DIODE 1SS133T-77
D708 8-719-991-33 DIODE 1SS133T-77 (AEP,UK,G,EE)
D901 8-719-200-82 DIODE 11ES2
D902 8-719-200-82 DIODE 11ES2
D903 8-719-200-82 DIODE 11ES2
D904 8-719-200-82 DIODE 11ES2
D905 8-719-200-82 DIODE 11ES2
< IC >
IC201 8-759-362-47 IC CXD8567AM
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
IC301 8-759-634-51 IC M5218AP
IC302 8-759-634-51 IC M5218AP
IC401 8-759-822-09 IC LB1641
IC701 8-759-821-93 IC LA5601
<JACK>
J301 1-770-719-11 JACK, PIN 2P (LINE OUT)
< COIL >
L201 1-410-322-11 INDUCTOR 3.3uH (EXCEPT CND)
L220 1-410-322-11 INDUCTOR 3.3uH
L251 1-410-322-11 INDUCTOR 3.3uH
L253 1-410-322-11 INDUCTOR 3.3uH
L254 1-410-397-21 FERRITE BEAD INDUCTOR 1.1uH (CND)
L254 1-410-507-11 INDUCTOR 6.8uH (EXCEPT CND)
L701 1-414-223-11 INDUCTOR 470uH
L702 1-412-473-21 INDUCTOR 0uH (CND)
< TRANSISTOR >
Q301 8-729-922-37 TRANSISTOR 2SD2144S
Q351 8-729-922-37 TRANSISTOR 2SD2144S
Q400 8-729-119-76 TRANSISTOR 2SA1175-HFE
Q401 8-729-019-64 TRANSISTOR 2SB1041
Q701 8-729-029-56 TRANSISTOR DTA144ESA
Q702 8-729-029-56 TRANSISTOR DTA144ESA
< RESISTOR >
R201 1-249-417-11 CARBON 1K 5% 1/4W
R202 1-247-807-00 CARBON 100 5% 1/4W
(CND)
R202 1-247-815-00 CARBON 220 5% 1/4W
(EXCEPT CND)
R203 1-249-417-11 CARBON 1K 5% 1/4W
R204 1-249-417-11 CARBON 1K 5% 1/4W
R205 1-249-417-11 CARBON 1K 5% 1/4W
R206 1-249-417-11 CARBON 1K 5% 1/4W
R207 1-249-417-11 CARBON 1K 5% 1/4W
R208 1-249-417-11 CARBON 1K 5% 1/4W
R220 1-247-815-00 CARBON 220 5% 1/4W
(CND)
R221 1-247-804-11 CARBON 75 5% 1/4W
(CND)
R221 1-249-400-11 CARBON 39 5% 1/4W
(EXCEPT CND)
R251 1-249-436-11 CARBON 39K 5% 1/4W
R252 1-249-436-11 CARBON 39K 5% 1/4W
R253 1-249-424-11 CARBON 3.9K 5% 1/4W
R255 1-249-436-11 CARBON 39K 5% 1/4W
R256 1-249-436-11 CARBON 39K 5% 1/4W
R257 1-247-807-00 CARBON 100 5% 1/4W
R301 1-249-431-11 CARBON 15K 5% 1/4W
R302 1-249-431-11 CARBON 15K 5% 1/4W
