Sony CDP-XE510 - Page 30

— 38 —
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
MAIN
< DIODE >
D601 8-719-200-82 DIODE 11ES2
D602 8-719-200-82 DIODE 11ES2
D603 8-719-200-82 DIODE 11ES2
D604 8-719-200-82 DIODE 11ES2
D605 8-719-200-82 DIODE 11ES2
D611 8-719-991-33 DIODE 1SS133T-77
D612 8-719-991-33 DIODE 1SS133T-77
D613 8-719-991-33 DIODE 1SS133T-77
D614 8-719-991-33 DIODE 1SS133T-77
D621 8-719-991-33 DIODE 1SS133T-77
D631 8-719-010-34 DIODE UZ-4.7BSC
D641 8-719-982-22 DIODE MTZJ-30D
D642 8-719-991-33 DIODE 1SS133T-77
D643 8-719-109-93 DIODE RD6.2ESB2
D681 8-719-991-33 DIODE 1SS133T-77
D682 8-719-991-33 DIODE 1SS133T-77
D691 8-719-991-33 DIODE 1SS133T-77
D692 8-719-991-33 DIODE 1SS133T-77
< GROUND TERMINAL >
EP601 1-537-770-21 TERMINAL BOARD, GROUND
< IC >
IC611 8-759-821-93 IC LA5601
IC621 8-752-880-21 IC CXP84332-036Q
IC631 8-759-822-09 IC LB1641
IC651 8-749-921-12 IC GP1F32T (DIGITAL OUT OPTICAL)
IC661 8-759-362-47 IC CXD8567AM
IC681 8-759-634-51 IC M5218AP
IC801 8-759-634-51 IC M5218AP
IC901 8-759-634-51 IC M5218AP
< JACK >
J621 1-774-726-11 JACK (S-LINK CONTROL-A1)
J681 1-770-719-11 JACK, PIN 2P (LINE OUT)
< COIL >
L611 1-414-223-11 INDUCTOR 470uH
L651 1-410-507-11 INDUCTOR 6.8uH
L652 1-410-322-11 INDUCTOR 3.3uH
L661 1-410-322-11 INDUCTOR 3.3uH
L662 1-410-322-11 INDUCTOR 3.3uH
L663 1-412-473-41 INDUCTOR 0uH
L664 1-412-473-41 INDUCTOR 0uH
L665 1-412-473-41 INDUCTOR 0uH
L671 1-410-507-11 INDUCTOR 6.8uH
L801 1-410-322-11 INDUCTOR 3.3uH
L901 1-410-322-11 INDUCTOR 3.3uH
< TRANSISTOR >
Q621 8-729-620-05 TRANSISTOR 2SC2603-EF
Q641 8-729-119-76 TRANSISTOR 2SA1175-HFE
Q642 8-729-019-65 TRANSISTOR 2SB1041T103
Q681 8-729-029-56 TRANSISTOR DTA144ESA
Q682 8-729-922-37 TRANSISTOR 2SD2144S
Q683 8-729-922-37 TRANSISTOR 2SD2144S
Q691 8-729-029-56 TRANSISTOR DTA144ESA
Q692 8-729-922-37 TRANSISTOR 2SD2144S
Q693 8-729-922-37 TRANSISTOR 2SD2144S
< RESISTOR >
R611 1-249-422-11 CARBON 2.7K 5% 1/4W F
R612 1-247-807-31 CARBON 100 5% 1/4W
R621 1-249-429-11 CARBON 10K 5% 1/4W
R622 1-249-429-11 CARBON 10K 5% 1/4W
R623 1-249-427-11 CARBON 6.8K 5% 1/4W F
R624 1-249-393-11 CARBON 10 5% 1/4W F
R625 1-249-429-11 CARBON 10K 5% 1/4W
R626 1-249-425-11 CARBON 4.7K 5% 1/4W F
R627 1-249-429-11 CARBON 10K 5% 1/4W
R631 1-249-427-11 CARBON 6.8K 5% 1/4W F
R641 1-249-432-11 CARBON 18K 5% 1/4W
R642 1-249-432-11 CARBON 18K 5% 1/4W
R643 1-249-441-11 CARBON 100K 5% 1/4W
R644 1-249-441-11 CARBON 100K 5% 1/4W
R645 1-249-425-11 CARBON 4.7K 5% 1/4W F
R646 1-249-432-11 CARBON 18K 5% 1/4W
R651 1-249-417-11 CARBON 1K 5% 1/4W F
R661 1-249-417-11 CARBON 1K 5% 1/4W F
R662 1-249-417-11 CARBON 1K 5% 1/4W F
R663 1-249-417-11 CARBON 1K 5% 1/4W F
R664 1-247-815-91 CARBON 220 5% 1/4W
R665 1-247-807-31 CARBON 100 5% 1/4W
R666 1-247-807-31 CARBON 100 5% 1/4W
R667 1-247-807-31 CARBON 100 5% 1/4W
R671 1-249-424-11 CARBON 3.9K 5% 1/4W F
R672 1-249-401-11 CARBON 47 5% 1/4W F
R673 1-247-807-31 CARBON 100 5% 1/4W
R681 1-249-441-11 CARBON 100K 5% 1/4W
R682 1-249-419-11 CARBON 1.5K 5% 1/4W F
R683 1-249-419-11 CARBON 1.5K 5% 1/4W F
R691 1-249-441-11 CARBON 100K 5% 1/4W
R692 1-249-419-11 CARBON 1.5K 5% 1/4W F
R693 1-249-419-11 CARBON 1.5K 5% 1/4W F
R801 1-249-436-11 CARBON 39K 5% 1/4W
R802 1-249-436-11 CARBON 39K 5% 1/4W
R803 1-249-431-11 CARBON 15K 5% 1/4W
R804 1-249-431-11 CARBON 15K 5% 1/4W
R805 1-249-437-11 CARBON 47K 5% 1/4W
R806 1-249-437-11 CARBON 47K 5% 1/4W
R807 1-249-419-11 CARBON 1.5K 5% 1/4W F
R808 1-249-419-11 CARBON 1.5K 5% 1/4W F
R809 1-249-441-11 CARBON 100K 5% 1/4W
R810 1-249-414-11 CARBON 560 5% 1/4W F
R812 1-247-807-31 CARBON 100 5% 1/4W
R821 1-249-403-11 CARBON 68 5% 1/4W F
R901 1-249-436-11 CARBON 39K 5% 1/4W
R902 1-249-436-11 CARBON 39K 5% 1/4W
R903 1-249-431-11 CARBON 15K 5% 1/4W
R904 1-249-431-11 CARBON 15K 5% 1/4W
R905 1-249-437-11 CARBON 47K 5% 1/4W
R906 1-249-437-11 CARBON 47K 5% 1/4W
R907 1-249-419-11 CARBON 1.5K 5% 1/4W F
