Sony CDP-XE510 - Component Identification and Part Numbers (Continued)

— 39 —
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
R908 1-249-419-11 CARBON 1.5K 5% 1/4W F
R909 1-249-441-11 CARBON 100K 5% 1/4W
R910 1-249-414-11 CARBON 560 5% 1/4W F
R912 1-247-807-31 CARBON 100 5% 1/4W
R921 1-249-403-11 CARBON 68 5% 1/4W F
< TRANSFORMER >
! T601 1-431-101-11 TRANSFORMER, POWER
< VIBRATOR >
X621 1-579-125-11 VIBRATOR, CERAMIC (4MHz)
X671 1-579-834-11 VIBRATOR, CRYSTAL (33MHz)
**************************************************************
* A-4699-484-A PANEL BOARD, COMPLETE
**********************
* 4-987-972-01 GUIDE (FL)
< CAPACITOR >
C501 1-161-494-00 CERAMIC 0.022uF 25V
C502 1-161-494-00 CERAMIC 0.022uF 25V
C503 1-164-159-21 CERAMIC 0.1uF 50V
C504 1-162-215-31 CERAMIC 47PF 5% 50V
C505 1-164-159-21 CERAMIC 0.1uF 50V
C506 1-161-494-00 CERAMIC 0.022uF 25V
C507 1-161-494-00 CERAMIC 0.022uF 25V
< CONNECTOR >
CN501 1-568-856-11 SOCKET, CONNECTOR 13P
< FLUORESCENT INDICATOR >
FL501 1-517-632-11 INDICATOR TUBE, FLUORESCENT
< IC >
IC501 8-759-451-97 IC MSM9202-03GS-BK
IC502 8-759-459-84 IC NJL56H400
< TRANSISTOR >
Q501 8-729-029-67 TRANSISTOR DTC114ESA-TP
Q502 8-729-029-67 TRANSISTOR DTC114ESA-TP
Q503 8-729-029-67 TRANSISTOR DTC114ESA-TP
< RESISTOR >
R501 1-249-427-11 CARBON 6.8K 5% 1/4W F
R502 1-249-415-11 CARBON 680 5% 1/4W F
R503 1-249-417-11 CARBON 1K 5% 1/4W F
R504 1-249-419-11 CARBON 1.5K 5% 1/4W F
R505 1-249-421-11 CARBON 2.2K 5% 1/4W F
R506 1-247-843-11 CARBON 3.3K 5% 1/4W
R507 1-249-427-11 CARBON 6.8K 5% 1/4W F
R508 1-249-431-11 CARBON 15K 5% 1/4W
R511 1-249-427-11 CARBON 6.8K 5% 1/4W F
R512 1-249-415-11 CARBON 680 5% 1/4W F
R513 1-249-417-11 CARBON 1K 5% 1/4W F
R514 1-249-419-11 CARBON 1.5K 5% 1/4W F
R515 1-249-421-11 CARBON 2.2K 5% 1/4W F
R516 1-247-843-11 CARBON 3.3K 5% 1/4W
R517 1-249-427-11 CARBON 6.8K 5% 1/4W F
R518 1-249-431-11 CARBON 15K 5% 1/4W
R519 1-249-437-11 CARBON 47K 5% 1/4W
R521 1-247-843-11 CARBON 3.3K 5% 1/4W
R522 1-247-807-31 CARBON 100 5% 1/4W
R523 1-249-417-11 CARBON 1K 5% 1/4W F
R524 1-249-417-11 CARBON 1K 5% 1/4W F
R525 1-249-417-11 CARBON 1K 5% 1/4W F
R526 1-249-417-11 CARBON 1K 5% 1/4W F
R531 1-249-441-11 CARBON 100K 5% 1/4W
R532 1-249-441-11 CARBON 100K 5% 1/4W
R533 1-249-441-11 CARBON 100K 5% 1/4W
R534 1-249-429-11 CARBON 10K 5% 1/4W
< SWITCH >
S501 1-554-303-21 SWITCH, TACTILE (§ OPEN/CLOSE)
S502 1-554-303-21 SWITCH, TACTILE (MUSIC SCAN)
S503 1-554-303-21 SWITCH, TACTILE (PEAK SEARCH)
S504 1-554-303-21 SWITCH, TACTILE (EDIT/TIMEFADE)
S505 1-554-303-21 SWITCH, TACTILE (PLAY MODE)
S506 1-554-303-21 SWITCH, TACTILE (REPEAT)
S507 1-554-303-21 SWITCH, TACTILE (TIME)
S511 1-554-303-21 SWITCH, TACTILE (CHECK)
S512 1-554-303-21 SWITCH, TACTILE (0)
S513 1-554-303-21 SWITCH, TACTILE ())
S514 1-554-303-21 SWITCH, TACTILE (ª)
S515 1-554-303-21 SWITCH, TACTILE (P)
S516 1-554-303-21 SWITCH, TACTILE (p)
S517 1-554-303-21 SWITCH, TACTILE (ENTER)
S518 1-554-303-21 SWITCH, TACTILE (CLEAR)
S521 1-473-452-11 ENCODER, ROTARY (≠ AMS ±)
**************************************************************
* 1-664-311-11 POWER SW BOARD
**************
< SWITCH >
S301 1-554-118-00 SWITCH, PUSH (1 KEY)(POWER)
**************************************************************
POWER SWPANEL
MAIN
The components identified by mark !
or dotted line with mark ! are critical
for safety.
Replace only with part number speci-
fied.
