— 40 —
Ref. No. Part No. Description Remark
MISCELLANEOUS
**************
13 1-769-971-11 WIRE (FLAT TYPE)(13 CORE)
22 1-776-100-11 WIRE (FLAT TYPE)(23 CORE)
! 24 1-575-651-21 CORD, POWER (AEP,EE,CIS)
! 24 1-696-907-11 CORD, POWER (UK)
* 101 1-452-538-11 MAGNET
! 151 8-848-379-31 OPTICAL PICK-UP KSS-213BA/F-NP
152 1-769-069-11 WIRE (FLAT TYPE)(16 CORE)
FL501 1-517-632-11 INDICATOR TUBE, FLUORESCENT
M101 X-4917-523-3 MOTOR ASSY (SPINDLE)
M102 X-4917-504-1 MOTOR ASSY (SLED)
M151 A-4672-207-A MOTOR (L) ASSY (LOADING)
! T901 1-431-101-11 TRANSFORMER, POWER
**************************************************************
ACCESSORIES & PACKING MATERIALS
*******************************
1-467-880-11 REMOTE COMMANDER (RM-D420)
1-558-271-11 CORD, CONNECTION (AUDIO 108cm)
3-810-765-71 MANUAL,COMMONNESS INSTRUCTION
(CONTROL-A1) (AEP,UK)
(ENGLISH,FRENCH,SPANISH,DUTCH,ITALIAN,
PORTUGUESE)
3-810-765-91 MANUAL,COMMONNESS INSTRUCTION
(CONTROL-A1) (EE,CIS)(ENGLISH,POLISH,
RUSSIAN)
3-858-571-11 MANUAL, INSTRUCTION
(ENGLISH,FRENCH,SPANISH)(AEP,UK)
3-858-571-21 MANUAL, INSTRUCTION
(GERMAN,DUTCH,ITALIAN,PORTUGUESE)(AEP)
3-858-571-31 MANUAL, INSTRUCTION
(SWEDISH,DANNISH,FINISH)(AEP)
3-858-571-41 MANUAL, INSTRUCTION
(ENGLISH,POLISH,RUSSIAN)(EE,CIS)
4-962-615-01 COVER, BATTERY (for RM-D420)
**************************************************************
*************
HARDWARE LIST
*************
#1 7-685-646-79 SCREW +BVTP 3X8 TYPE2 N-S
#2 7-621-775-10 SCREW +B 2.6X4
#3 7-621-255-15 SCREW +P 2X3
#4 7-685-134-19 SCREW +BTP 2.6X8 TYPE2 N-S
CDP-XE510
The components identified by mark !
or dotted line with mark ! are critical
for safety.
Replace only with part number speci-
fied.
9-960-908-11
Sony Corporation
Home A&V Products Company
97C097553-1
Printed in Hungary © 1997. 3
Published by Service and Safety
Engineering Dept. (Shibaura)
