— 37 —
R936 1-247-807-31 CARBON 100 5% 1/4W
R937 1-249-417-11 CARBON 1K 5% 1/4W F
R938 1-247-807-31 CARBON 100 5% 1/4W
R939 1-249-425-11 CARBON 4.7K 5% 1/4W F
R940 1-247-843-11 CARBON 3.3K 5% 1/4W
R941 1-249-428-11 CARBON 8.2K 5% 1/4W F
R942 1-249-425-11 CARBON 4.7K 5% 1/4W F
R943 1-249-425-11 CARBON 4.7K 5% 1/4W F
R944 1-247-807-31 CARBON 100 5% 1/4W
R945 1-249-425-11 CARBON 4.7K 5% 1/4W F
R946 1-249-429-11 CARBON 10K 5% 1/4W
R947 1-249-417-11 CARBON 1K 5% 1/4W F
< VIBRATOR >
X301 1-760-955-11 VIBRATOR, CRYSTAL (45MHz)
**************************************************************
* 1-662-405-11 POWER BOARD
***********
< CAPACITOR >
C901 1-164-159-11 CERAMIC 0.1uF 50V
(XE900E:CH)
C901 1-164-159-21 CERAMIC 0.1uF 50V
(XE900/XE900E:UK)
C902 1-164-159-11 CERAMIC 0.1uF 50V
(XE900E:CH)
C902 1-164-159-21 CERAMIC 0.1uF 50V
(XE900/XE900E:UK)
C911 1-128-198-11 ELECT 22uF 20% 63V
C930 1-117-149-21 ELECT 2200uF 20% 25V
(XE900E:UK)
C930 1-126-234-11 ELECT 2200uF 20% 16V
(XE900/XE900E:CH)
C931 1-115-463-11 CAPACITOR 5600uF 20% 16V
(XE900/XE900E:CH)
C931 1-117-150-21 ELECT 5600uF 20% 25V
(XE900E:UK)
C934 1-115-197-11 ELECT 100uF 20% 25V
(XE900E:UK)
< CONNECTOR >
CN903 1-766-269-11 PIN, CONNECTOR (PC BOARD) 7P
< DIODE >
D910 8-719-200-82 DIODE 11ES2
D914 8-719-200-82 DIODE 11ES2
D915 8-719-200-82 DIODE 11ES2
D916 8-719-200-82 DIODE 11ES2
D930 8-719-210-21 DIODE 11EQS04
D931 8-719-210-21 DIODE 11EQS04
D932 8-719-210-21 DIODE 11EQS04
D933 8-719-210-21 DIODE 11EQS04
< GROUND TERMINAL >
* EB601 1-537-738-21 TERMINAL, EARTH (XE900/XE900E:UK)
EB601 1-537-770-21 TERMINAL BOARD, GROUND (XE900E:CH)
< COIL >
L901 1-412-473-21 INDUCTOR 0uH (XE900E:CH)
L901 1-412-473-41 INDUCTOR 0uH (XE900/XE900E:UK)
L902 1-412-473-21 INDUCTOR 0uH (XE900E:CH)
L902 1-412-473-41 INDUCTOR 0uH (XE900/XE900E:UK)
**************************************************************
* 1-658-709-11 SLED BOARD
**********
< CONNECTOR >
CN104 1-774-380-11 CONNECTOR, FFC/FPC 16P
CN105 1-568-838-11 SOCKET, CONNECTOR 21P
* CN106 1-750-737-11 CONNECTOR, FFC/FPC 5P
< MOTOR >
M102 X-4947-303-1 MOTOR ASSY (SLED)
**************************************************************
* 1-658-708-11 SPINDLE BOARD
*************
< CONNECTOR >
* CN107 1-568-848-11 SOCKET, CONNECTOR 5P
< MOTOR >
M101 X-4947-304-1 MOTOR ASSY (SPINDLE)
< SWITCH >
S151 1-571-958-11 SWITCH, PUSH (1 KEY)(LIMIT SW)
**************************************************************
* 1-659-494-11 TRANS BOARD
***********
< CONNECTOR >
* CN901 1-580-230-31 PIN, CONNECTOR (PC BOARD) 2P
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
TRANSMAIN POWER
SLED
SPINDLE
