— 38 —
Ref. No. Part No. Description Remark
< TRANSFORMER >
! T901 1-429-766-11 TRANSFORMER, POWER
**************************************************************
MISCELLANEOUS
*************
55 1-776-235-11 WIRE (FLAT TYPE)(23 CORE)
! 62 1-569-008-11 ADAPTOR, CONVERSION 2P (XE900E:CH)
101 1-452-820-11 MAGNET (ASSY)
105 1-776-998-11 WIRE (FLAT TYPE)(21 CORE)
157 1-775-990-11 WIRE (FLAT TYPE)(5 CORE)
! 160 8-848-376-01 OPTICAL PICK-UP BLOCK KSS-213B/S-N
161 1-775-991-11 WIRE (FLAT TYPE)(16 CORE)
! CNP901 1-575-651-21 CORD, POWER (XE900/XE900E:CH)
! CNP901 1-696-907-11 CORD, POWER (XE900E:UK)
FLD801 1-519-757-11 INDICATOR TUBE, FLUORESCENT
M101 X-4947-304-1 MOTOR ASSY (SPINDLE)
M102 X-4947-303-1 MOTOR ASSY (SLED)
M151 A-4660-968-A MOTOR ASSY (LOADING)
! T901 1-429-766-11 TRANSFORMER, POWER
**************************************************************
ACCESSORIES & PACKING MATERIALS
*******************************
1-473-125-11 REMOTE COMMANDER (RM-D820)
1-590-925-31 CORD, CONNECTION (AUDIO 1m)
3-810-116-11 MANUAL, INSTRUCTION
(ENGLISH,FRENCH,SPANISH,SWEDISH)
(XE900:AEP/XE900E:UK)
3-810-116-21 MANUAL, INSTRUCTION
(GERMAN,DUTCH,ITALIAN,PORTUGUESE)
(XE900:AEP)
3-810-116-31 MANUAL, INSTRUCTION (GERMAN)(XE900:G)
3-810-116-51 MANUAL, INSTRUCTION
(ENGLISH,FRENCH,SPANISH,CHINESE)
(XE900E:CH)
4-962-615-01 COVER, BATTERY (for RM-D820)
* 4-981-603-01 INDIVIDUAL CARTON (XE900E:CH)
* 4-984-636-01 CUSHION (XE900E:CH)
* 4-985-137-01 INDIVIDUAL CARTON (XE900E:CH)
* 4-985-487-01 INDIVIDUAL CARTON (XE900)
* 4-985-488-01 CUSHION (XE900/XE900E:UK)
* 4-985-489-01 INDIVIDUAL CARTON (XE900E:UK)
**************************************************************
*************
HARDWARE LIST
TRANS
The components identified by
mark ! or dotted line with mark
! are critical for safety.
Replace only with part number
specified.
Sony Corporation
Home A&V Products Company
9-960-716-11
English
96F0961-1
Printed in Japan
© 1996.6
Published by Quality Engineering Dept.
(Shibaura)
*************
#1 7-685-646-79 SCREW +BVTP 3X8 TYPE2 N-S
#2 7-685-871-01 SCREW +BVTT 3X6 (S)
#3 7-682-548-04 SCREW +BVTT 3X8 (S)
#4 7-627-852-07 SCREW, PRECISION +P 1.7X2.5
#5 7-621-772-10 SCREW +B 2X4
Ref. No. Part No. Description Remark
