Specifications
■ General
Host interface ATAPI compliant
Disc
Acceptable discs CD-Digital Audio discs
CD-ROM mode-1 data discs
CD-ROM mode-2 form 1 / form 2 data discs
CD-ROM XA discs (readable)
Audio-combined CD-ROM discs
CD-I discs (readable)
CD-I Ready discs (readable)
CD Bridge discs
Photo CD discs (single and multi session)
CD EXTRA dics
Rotational speed
Innermost track 530 min
-1
(530 rpm/1X)
2120 min
-1
(2120 rpm/4X)
4240 min
-1
(4240 rpm/8X)
Outermost track 200 min
-1
(200 rpm/1X)
800 min
-1
(800 rpm/4X)
1600 min
-1
(1600 rpm/8X)
■ Drive performance
Data transfer rate
Sustained rate 150 kBytes/s (1X)
600 kBytes/s (4X)
1200 kBytes/s (8X)
Burst rate 11.1 MBytes/s (PIO mode 3)
I/O CHANNEL READY supported
13.3 MBytes/s (Multiword DMA mode 1)
Access time
(Random stroke) 160 ms (typical/8X)
■ Reliability
Read error rate (includes retry, with a standard disc)
L-EC on 1 block/10
12
bits
L-EC off 1 block/10
9
bits
■ Audio
Output level
Line out 0.75 V at 47 kΩ
Headphone 0.55 V at 32 Ω
26 Operating the Drive
When the drive’s right side is down
To facilitate disc handling, set the disc locks B, C and D into the locked
position, and leave the disc lock A in the unlocked position.
When the drive’s left side is down
To facilitate disc handling, set the disc locks A, C and D into the locked
position, and leave the disc lock B in the unlocked position.
Specifications 27
