Pin No. Pin Name I/O Pin Description
49 – 63 LCD25 – LCD11 O Not used.
64 LCD10 O Not used.
65 TEST SW(LCD9) I/O Test mode direct settig input
66 BAND SW(LCD8) I/O Not used.
67 AREA2 SW(LCD7) O Not used.
68 AREA1 SW(LCD6) I/O Not used.
69, 70 LCD5, LCD4 O Not used.
71 SELF SW(LCD3) I/O SELF SW input/LCD segment signal output pin
72 IN SW(LCD2) I/O DISC IN SW input/LCD segment signal output pin
73 L SW(LCD1) I/O LIMIT SW input/LCD segment signal output pin
74 D SW(LCD0) I/O DOWN SW input/LCD segment signal output pin
75 KEY-RETURN I Key return signal input pin
76 – 78 AD2 – AD0 I Key input pin (A/D input)
79 AMP MUTE O Power amplifier mute signal output pin
80 CD CKO O CD serial clock output pin
