Sony CDX-3167 - Electrical Parts List; Disc In SW and Display Components; Capacitors and Diodes; Resistors and Semiconductors

– 47 –
SECTION 6
ELECTRICAL PARTS LIST
NOTE:
•Due to standardization, replacements in
the parts list may be different from the
parts specified in the diagrams or the
components used on the set.
•-XX and -X mean standardized parts, so
they may have some difference from the
original one.
•RESISTORS
All resistors are in ohms.
METAL:Metal-film resistor.
METAL OXIDE: Metal oxide-film resistor.
F:nonflammable
•Items marked “*” are not stocked since
they are seldom required for routine service.
Some delay should be anticipated
when ordering these items.
•SEMICONDUCTORS
In each case, u : µ, for example:
uA..: µA.. uPA..: µPA..
uPB..: µPB..uPC..: µPC.. uPD.. : µPD..
•CAPACITORS
uF : µF
•COILS
uH : µH
The components identified by mark
! or dotted line with mark. ! are
critical for safety.
Replace only with part number
specified.
When indicating parts by reference
number, please include the board.
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
* 1-659-836-11DISC IN SW BOARD
****************
< SWITCH >
SW1 1-572-288-11SWITCH, PUSH (DISC IN)
SW2 1-572-288-11SWITCH, PUSH (SELF)
************************************************************
DISPLAY BOARD
**************
* 3-009-335-01PLATE (LCD), LIGHT GUIDE
* 3-009-337-01HOLDER (LCD)
* 3-009-341-01SHEET (LCD)
* Y-8283-681-A PCI DISPLAY, ASSY
< CAPACITOR >
C851 1-163-137-00CERAMIC CHIP 680PF 5% 50V
C852 1-163-038-00CERAMIC CHIP 0.1uF 25V
C853 1-163-117-00CERAMIC CHIP 100PF 5% 50V
< CONNECTOR >
CNP8011-764-423-11PIN, CONNECTOR 12P
*CNP8021-779-129-11PIN, CONNECTOR 3P
< DIODE >
D851 8-719-976-99DIODE DTZ5.1B
D852 8-719-052-61LED SLR-342PGT31 (SENS)
D853 8-719-052-61LED SLR-342PGT31 (6)
D854 8-719-052-61LED SLR-342PGT31 (A.MEM)
D855 8-719-052-61LED SLR-342PGT31 (6)
D856 8-719-052-61LED SLR-342PGT31 (2/REPEAT)
D857 8-719-052-61LED SLR-342PGT31 (3/SHUF)
D858 8-719-052-61LED SLR-342PGT31 (4)
D859 8-719-064-19LED SLR-342PG (5)
D860 8-719-052-61LED SLR-342PGT31 (SEL)
D861 8-719-052-61LED SLR-342PGT31 (MODE)
D862 8-719-052-61LED SLR-342PGT31 (SOURCE)
D863 8-719-052-61LED SLR-342PGT31 (+)
D864 8-719-052-61LED SLR-342PGT31 (MUTE)
D865 8-719-052-61LED SLR-342PGT31 (-)
D868 8-719-052-61LED SLR-342PGT31 (DSPL)
D869 8-719-052-61LED SLR-342PGT31 (OFF)
D870 8-719-052-61LED SLR-342PGT31 (1/INTRO)
D872 8-719-105-99DIODE RD6.2M-B1
D873 8-719-105-99DIODE RD6.2M-B1
D874 8-719-105-99DIODE RD6.2M-B1
D875 8-719-105-99DIODE RD6.2M-B1
< IC >
IC801 8-759-369-90IC LC75822ED
< JUMPER RESISTOR >
JR801 1-216-295-00CONDUCTOR, CHIP (2012)
JR802 1-216-295-00CONDUCTOR, CHIP (2012)
JR804 1-216-296-00CONDUCTOR, CHIP (3216)
JR805 1-216-296-00CONDUCTOR, CHIP (3216)
JR806 1-216-296-00CONDUCTOR, CHIP (3216)
JR807 1-216-296-00CONDUCTOR, CHIP (3216)
JR808 1-216-296-00CONDUCTOR, CHIP (3216)
JR809 1-216-296-00CONDUCTOR, CHIP (3216)
JR810 1-216-296-00CONDUCTOR, CHIP (3216)
JR811 1-216-296-00CONDUCTOR, CHIP (3216)
JR812 1-216-296-00CONDUCTOR, CHIP (3216)
JR816 1-216-295-00CONDUCTOR, CHIP (2012)
JR817 1-216-295-00CONDUCTOR, CHIP (2012)
JR818 1-216-295-00CONDUCTOR, CHIP (2012)
< LIQUID CRYSTALDISPLAY >
LCD8001-801-674-12DISPLAY PANEL, LIQUID CRYSTAL
< PILOT LAMP >
PL801 1-517-677-11LAMP, PILOT
PL802 1-517-677-11LAMP, PILOT
< RESISTOR >
R841 1-216-193-11METAL CHIP 6205% 1/8W
R842 1-216-193-11METAL CHIP 6205% 1/8W
R851 1-216-090-00METAL CHIP 51K5% 1/10W
R852 1-216-049-11METAL GLAZE 1K 5% 1/10W
DISC IN SW DISPLAY
