– 48 –
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
DISPLAY
R854 1-247-806-11CARBON 91 5% 1/4W
R855 1-247-806-11CARBON 91 5% 1/4W
R856 1-247-818-11CARBON 3005% 1/4W
R857 1-247-818-11CARBON 3005% 1/4W
R859 1-247-818-11CARBON 3005% 1/4W
R860 1-247-822-11CARBON 4305% 1/4W
R861 1-216-053-00METAL CHIP 1.5K5% 1/10W
R862 1-216-057-00METAL CHIP 2.2K5% 1/10W
R863 1-247-843-11CARBON 3.3K5% 1/4W
R864 1-216-067-00METAL CHIP 5.6K5% 1/10W
R865 1-249-429-11CARBON 10K5% 1/4W
R871 1-216-053-00METAL CHIP 1.5K5% 1/10W
R872 1-216-057-00METAL CHIP 2.2K5% 1/10W
R873 1-216-061-00METAL CHIP 3.3K5% 1/10W
R874 1-216-067-00METAL CHIP 5.6K5% 1/10W
R875 1-216-073-00METAL CHIP 10K5% 1/10W
R876 1-216-053-00METAL CHIP 1.5K5% 1/10W
R877 1-216-057-00METAL CHIP 2.2K5% 1/10W
R878 1-247-843-11CARBON 3.3K5% 1/4W
R879 1-216-067-00METAL CHIP 5.6K5% 1/10W
R880 1-216-073-00METAL CHIP 10K5% 1/10W
R881 1-216-083-00METAL CHIP 27K5% 1/10W
R882 1-247-806-11CARBON 91 5% 1/4W
< SWITCH >
S801 1-572-704-31SWITCH, KEY BOARD (6)
S802 1-572-704-31SWITCH, KEY BOARD (A.MEM)
S803 1-572-704-31SWITCH, KEY BOARD (SENS)
S804 1-572-704-31SWITCH, KEY BOARD (4)
S805 1-572-704-31SWITCH, KEY BOARD (5)
S806 1-572-704-31SWITCH, KEY BOARD (6)
S808 1-572-704-31SWITCH, KEY BOARD (SOURCE)
S809 1-572-704-31SWITCH, KEY BOARD (MODE)
S811 1-572-704-31SWITCH, KEY BOARD (- = 0 (SEEK/AMS))
S812 1-572-704-31SWITCH, KEY BOARD (SEL)
S813 1-572-704-31SWITCH, KEY BOARD (+)
S815 1-572-704-31SWITCH, KEY BOARD (OFF)
S816 1-572-704-31SWITCH, KEY BOARD (MUTE)
S817 1-572-704-31SWITCH, KEY BOARD (-)
S818 1-572-704-31SWITCH, KEY BOARD (DSPL)
S819 1-572-704-31SWITCH, KEY BOARD (1/INTRO)
S820 1-572-704-31SWITCH, KEY BOARD (2/REPEAT)
S821 1-572-704-31SWITCH, KEY BOARD (3/SHUF)
************************************************************
DISPLAY SUB BOARD
******************
< DIODE >
D866 8-719-052-61LED SLR-342PGT31 (- = 0 (SEEK/AMS))
D867 8-719-052-61LED SLR-342PGT31 (+ + ) (SEEK/AMS))
< SWITCH >
S810 1-572-704-31SWITCH, KEY BOARD (+ + ) (SEEK/AMS))
************************************************************
* 1-659-835-12LIMIT SW BOARD
***************
< SWITCH >
SW3 1-572-688-11SWITCH, PUSH (1 KEY) (LIMIT)
************************************************************
* 1-659-837-11LOAD SW BOARD
***************
< SWITCH >
SW4 1-572-288-11SWITCH, PUSH (DOWN)
************************************************************
*Y-8283-355-A MAIN BOARD, COMPLETE
*********************
* 3-009-353-01HEAT SINK
* 3-920-529-01BRACKET (REG) (IC)
* 3-931-260-01BRACKET (IC)
7-685-792-09SCREW +PTT 2.6X6 (S)
7-685-793-09SCREW +PTT 2.6X8 (S)
< CAPACITOR >
C101 1-164-161-11CERAMIC CHIP 0.0022uF 10% 100V
C102 1-164-346-11CERAMIC CHIP 1uF 16V
C103 1-164-346-11CERAMIC CHIP 1uF 16V
C104 1-164-004-11CERAMIC CHIP 0.1uF 10% 25V
C105 1-163-017-00CERAMIC CHIP 0.0047uF 5% 50V
C106 1-126-157-11ELECT 10uF 20% 16V
C107 1-164-489-11CERAMIC CHIP 0.22uF 10% 16V
C108 1-163-235-11CERAMIC CHIP 22PF 5% 50V
C109 1-126-157-11ELECT 10uF 20% 16V
C110 1-126-157-11ELECT 10uF 20% 16V
C111 1-126-157-11ELECT 10uF 20% 16V
C112 1-126-157-11ELECT 10uF 20% 16V
C113 1-163-009-11CERAMIC CHIP 0.001uF 10% 50V
C114 1-164-005-11CERAMIC CHIP 0.47uF 25V
C115 1-164-005-11CERAMIC CHIP 0.47uF 25V
LIMIT SW LOAD SW MAINDISPLAY SUB
