Sony CDX-3167 - Page 21

– 28 –
• Waveforms (MODE:PLAY)
1
2
3
4
5
6
7
Approx. 620mVp-p
IC2
1
(FEO)
0V
IC2
#¡
(RFO)
1.2Vp-p
Approx. 200mVp-p
IC2
$™
(TEO)
0V
IC1
3
(MDP)
2.6Vp-p
7.6µsec
IC1
@º
(LRCK)
5.8Vp-p
22.7µsec
IC1
@™
(BCK)
5.7Vp-p
474nsec
16.89MHz
IC1
#¢
(XTAI)
3.2Vp-p
