Sony CDX-3167 - Page 34

– 50 –
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
MAIN
C917 1-124-465-00ELECT 0.47uF 20% 50V
C918 1-164-004-11CERAMIC CHIP 0.1uF 10% 25V
C922 1-126-966-11ELECT 33uF 20% 16V
C923 1-124-257-00ELECT 2.2uF 20% 50V
< JACK >
CNJ6001-779-005-11JACK (ANTENNA)
< CONNECTOR >
CNP5011-774-701-11PIN, CONNECTOR 16P
CNP7001-764-617-12PIN, CONNECTOR (PC BOARD) 30P
CNP8001-764-422-11PLUG, CONNECTOR 12P
< DISCHARGE GAP >
CP6011-519-504-32GAP, DISCHARGE
< DIODE >
D400 8-719-109-71DIODE RD3.9ES-B1
D401 8-719-986-73DIODE RB441Q
D411 8-719-991-33DIODE 1SS133T-77
D638 8-719-991-33DIODE 1SS133T-77
D803 8-719-991-33DIODE 1SS133T-77
D804 8-719-991-33DIODE 1SS133T-77
D805 8-719-991-33DIODE 1SS133T-77
D810 8-719-991-33DIODE 1SS133T-77
D811 8-719-109-93DIODE RD6.2ESB2
D812 8-719-109-93DIODE RD6.2ESB2
D813 8-719-109-93DIODE RD6.2ESB2
D814 8-719-109-93DIODE RD6.2ESB2
D815 8-719-109-93DIODE RD6.2ESB2
D816 8-719-109-93DIODE RD6.2ESB2
D817 8-719-109-93DIODE RD6.2ESB2
D818 8-719-109-93DIODE RD6.2ESB2
D9018-719-923-92
DIODE MTZJ-T-77-16B
D903 8-719-109-93DIODE RD6.2ESB2
D905 8-719-923-93DIODE MTZJ-T-77-16C
D908 8-719-991-33DIODE 1SS133T-77
D9098-719-048-54
DIODE MTZJ-T-77-10A
D911 8-719-109-89DIODE RD5.6ESB2
D912 8-719-109-93DIODE RD6.2ESB2
D913 8-719-049-38DIODE 1N5404TU
D914 8-719-991-33DIODE 1SS133T-77
D915 8-719-109-97DIODE RD6.8ESB2
D918 8-719-110-13DIODE RD9.1ESB2
D9198-719-200-82DIODE 11ES2
< FUSE >
F501 1-532-877-11FUSE (BLADE TYPE) (AUTO FUSE) 10A
< IC >
IC200 8-759-369-41IC HA13155
IC4008-752-075-48IC CXA1946AQ-T6
IC700 8-759-364-35IC SM5877AM-E2
IC8008-759-454-66IC uPD17017GF-B28-3B9
IC900 8-759-095-61IC S-81250PG-Z
< JUMPER RESISTOR >
JR2 1-216-296-00CONDUCTOR, CHIP (3216)
JR10 1-216-295-00CONDUCTOR, CHIP (2012)
JR11 1-216-296-00CONDUCTOR, CHIP (3216)
JR14 1-216-295-00CONDUCTOR, CHIP (2012)
JR15 1-216-295-00CONDUCTOR, CHIP (2012)
JR17 1-216-295-00CONDUCTOR, CHIP (2012)
JR18 1-216-295-00CONDUCTOR, CHIP (2012)
JR19 1-216-295-00CONDUCTOR, CHIP (2012)
< COIL >
L400 1-410-513-11INDUCTOR 22uH
L600 1-410-513-11INDUCTOR 22uH
L601 1-410-521-11INDUCTOR 100uH
L603 1-216-296-00CONDUCTOR, CHIP (3216)
L700 1-410-521-11INDUCTOR 100uH
L800 1-410-513-11INDUCTOR 22uH
L801 1-410-513-11INDUCTOR 22uH
L901 1-411-823-21COIL, CHOKE (TROIDAL)
< JACK >
PJ400 1-764-697-11JACK, PIN 4P (LINE OUT FRONT/REAR)
< TRANSISTOR >
Q101 8-729-920-21TRANSISTOR DTC314TKH04
Q102 8-729-920-21TRANSISTOR DTC314TKH04
Q201 8-729-920-21TRANSISTOR DTC314TKH04
Q202 8-729-920-21TRANSISTOR DTC314TKH04
Q404 8-729-901-05TRANSISTOR DTA124EK
Q405 8-729-901-00TRANSISTOR DTC124EK
Q604 8-729-920-74TRANSISTOR 2SC2412K-QR
Q605 8-729-920-74TRANSISTOR 2SC2412K-QR
Q607 8-729-901-98TRANSISTOR 2SA1036K-R
Q608 8-729-900-53TRANSISTOR DTC114EK
Q609 8-729-920-74TRANSISTOR 2SC2412K-QR
Q804 8-729-901-05TRANSISTOR DTA124EK
Q901 8-729-822-84TRANSISTOR 2SB1202FAST
Q903 8-729-900-53TRANSISTOR DTC114EK
Q904 8-729-920-74TRANSISTOR 2SC2412K-QR
Q905 8-729-920-74TRANSISTOR 2SC2412K-QR
Q907 8-729-901-05TRANSISTOR DTA124EK
