Sony CDX-CA600 - Lever Section; Servo Board

10
CDX-CA600/CA600X
5 special screws
1 CN3
2 Removal the solders.
3 P 2x3
4 loading motor assy
7 SERVO board
6 special screw
8 connector
optical pick-up bloc
k
4 claws
2 IN SELF SW board
7 lever (L)
3 tension spring (LR)
6 lever (R)
5 guide (disc)
1 special screw
2-6. LEVER SECTION
2-7. SERVO BOARD
